Summary of Contents for Taurus TF-X105-2
- Page 1 Assembly and Operating Instructions max. 180 kg ~ 60 Min. 95 kg L 232 | W 95 | H 172 TFX105.02.05 Art.No. TF-X105-2 Crosstrainer X10.5 Pro...
- Page 2 X10.5...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button functions Powering on the crosstrainer Standby mode MANUAL (Manual programmes) 3.5.1 Quick-Start programme 3.5.2 Target programmes PROGRAM (Profile programmes) USER (User defined programme) H.R.C. - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT X10.5...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data LCD Display: Speed in km/h RPM (Revolutions per minute) Training duration in min. Distance in km Calories burned in kcal Heart rate (using the hand pulse sensors or a chest strap) Watts Resistance system: Electro-magnetic induction brake Resistance levels: Wattage Adjustable range in the watt programme:... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Electrical Safety
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Mounting the front and rear feet NOTICE... - Page 13 Step 2: Mounting the console mast Slide the cover (62) up around the console mast (4) (see fig. 2-1) and connect cable (98) to cable (99) (see fig. 2-2). Place the console mast (4) in the holder in the main frame (1) and screw it in with four hexagonal screws (13), four spring washers (12) and four washers (11).
- Page 14 Step 3: Mounting the console and arms Mount the left and right poles (6) onto the console mast (4) with two hexagonal screws (13), two spring washers (12) and four washers (11) each. Connect cable (117) to cable (98) (see fig. 3-1). Place the console (117) on the console mast (4) and screw into place with four screws (17) (see fig.
- Page 15 Step 4: Mounting the pedal rails and handlebar Connect the cables (117 & 102) and the cables (117 & 103) with each other (see fig. 4-1). Mount the handlebar (5) onto the console mast (4) with two hexagonal screws (73) and two curved washers (74).
- Page 16 Step 5: Mounting the handles and pedals Mount the right handle (10R) onto the right pole (6) with three hexagonal screws (73), three curved washers (74) and three locking nuts (20) (see fig. 5-1). Mount the left handle (10L) onto the left pole (6) with three hexagonal screws (73), three curved washers (74) and three locking nuts (20) (see fig.
- Page 17 Step 6: Mounting the covers Assemble the drink bottle holder parts (71 & 72) together and screw into place on the console mast (4) with four screws (64). Click the front drink bottle holder cover (70) onto the drink bottle holder (71) (see fig.
- Page 18 Step 8: Adjusting the feet The crosstrainer can be stabilised on un-even surfaces with the adjustable feet. Lift up the crosstrainer on one side to gain access to the adjustable feet underneath the frame. Turn the screw clockwise to unscrew the foot, lifting the crosstraining at that point. Turn the screw anti-clockwise to lower the crosstrainer at that point.
-
Page 19: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console display DISPLAY DESCRIPTION Display of the elapsed training time (0:00 - 99:59) TIME Set a target time with the rotary knob (0:00 - 99:00) in 1 min. -
Page 20: Button Functions
Button functions BUTTON DESCRIPTION Increasing the setting value or resistance level Rotary knob Decreasing the setting value or resistance level Setting confirmation BODY FAT Body fat test RECOVERY Heart rate test on your recovery condition Returns you to the previous training mode while making settings or RESET selecting an option. -
Page 21: Powering On The Crosstrainer
Powering on the crosstrainer The console starts automatically as soon as the crosstrainer is plugged into the mains supply. Various components will light up. Choose a user profile (U1 - U4). Enter in your gender (SEX), age (AGE), height (HEIGHT) and weight (WEIGHT). You will proceed onto the main menu. -
Page 22: Manual (Manual Programmes)
MANUAL (Manual programmes) Under MANUAL you can choose between the Quick-Start programme and one of the target programmes. For target programmes, settings for time (TIME), distance (DISTANCE), caloires (CALORIES) or heart rate (PULSE) are possible. 3.5.1 Quick-Start programme In the main menu, select MANUAL and confirm your choice with a single push of the rotary knob. -
Page 23: Program (Profile Programmes)
Training with multiple target values In the main menu select MANUAL and confirm your choice with a single push of the rotary knob. Select your target value for time, calories, distance and/or heart rate with the rotary knob and confirm your choice with a single push of the rotary knob. ⚠... - Page 24 X10.5...
-
Page 25: User (User Defined Programme)
USER (User defined programme) There are 16 segments available in user defined programmes. In the main menu select USER and confirm your choice with a single push of the rotary knob. Select the resistance level of each segment and confirm each value with a single push of the rotary knob. -
Page 26: Heart Rate Controlled Programmes)
H.R.C. (Heart rate controlled programmes) WARNING ⚠ This crosstrainer is not medical equipment. The heart rate measurement of the crosstrainer can be unprecise. Different factors can influence the heart rate reading. The heart rate readings are only meant as a guide for training. There are four heart rate programmes available to choose from. -
Page 27: Watt (Watt Programme)
WATT (Watt programme) In the main menu select WATT and confirm your choice with a single push of the rotary knob. Using the rotary knob, select a Watt value and confirm your setting with a single push of the rotary knob. NOTICE The pre-set value is 120. -
Page 28: Body Fat (Body Fat Analysis)
3.11 BODY FAT (Body fat analysis) Choose your user profile (U1-U4). To start the body fat analysis, in the main menu press the BODY FAT button and hold on to the hand pulse sensors. NOTICE Should you not properly grip the hand pulse sensors, the display will show the error code E-1. NOTICE If you wish to prematurley end the body fat analysis and return to the previous program, press the BODY FAT button again. -
Page 29: Bluetooth And Fitness Apps
3.12 Bluetooth and fitness apps This console is equipped with a bluetooth interface. Please take note that your mobile device needs to be compatible with the bluetooth interface of the treadmill (bluetooth 4.0). To use training apps you will have to activate the bluetooth function on your mobile device (tablet or smart phone) and start the fitness app. -
Page 30: Storage And Transport
STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠... -
Page 31: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 32: Error Codes And Troubleshooting
Error codes and troubleshooting The electronics of the crosstrainer are continually running tests. In case of deviations, an error code is shown on the display and normal operation is stopped for your safety. No values were received during the body fat analysis. Make sure that, during the analysis, you hold on to the hand pulse sensors with both hands. -
Page 33: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Slide rails* Lubrication of slide rails and moving parts*... - Page 34 This unit contains a rechargeable 12V 2.6 Ah lead-acid battery (Sealed Lead Acid battery, SLA battery for short). For proper disposal of the unit, the installed SLA battery must first be removed. It is located underneath the frame. ⚠ CAUTION The following steps must be carried out by two people.
-
Page 35: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 36: Ordering Spare Parts
Standard/Norm: Maximum weight/max. Benutzergewicht: Class/Klasse: Date/Datum: Sport-Tiedje GmbH, Flensburger Str. 55, 24837 Schleswig MADE IN Serial nº.: Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Crosstrainer Model Name: X10.5 Article Number: TF-X10.5-2 X10.5... -
Page 37: Parts List
Parts List Name Supplier Parts No. Specification Qty. Main frame 749G1-3-1000-BA0 Front stabilizer 749S0-3-2100-BA1 Rear stabilizer 749S0-3-2112-BA1 Handlebar post 749S0-3-2000-BA2 Handlebar 749S0-3-2400-BA0 Supporting tube for moveable 749S0-3-3700-BA0 handlebar Right pedal supporting tube 749S0-3-3810-BA1 Left pedal supporting tube 749S0-3-3811-BA1 Crank 749S0-3-2700-B1 Fixing plate for idle wheel 747S0-3-1600-00 Right dip foam... - Page 38 Hex bolt 50106-2-0075-N0 M6*75L Fixing plate 815G0-6-1673-N0 20*27*4T Allen screw 54006-5-0015-D0 M6*1.0*15L 55206-2-2005-NA M6*1*5T Bearing 58006-6-1059-00 #6205-2RS1,SKF Allen bolt 54010-8-0065-F6 M10*1.5*65L 55210-A-2008-FA M10*1.5*8T Spacer 75000-6-2781-01 D29.5*D25.2*9T Bolt 50108-2-0020-U0 M8*1.25*20L Flat washer 55108-1-2115-CA D21*D8.5*1.5T Sleeve 747S0-6-2707-00 D30*D25.2*45L Belt 58004-6-1115-00 540 PJ8 Pulley wheel 58008-6-1036-D0 D350*29.9*3T...
- Page 39 Upper protective cover 734S0-6-4580-B0 170*147*125.5 Front foot cover 749S0-6-3775-B0 784.9*144.6*142.4 Screw 52842-2-0015-F0 ST4.2*15L 71600-6-4586-60 D6*26.5*7.7 Buffer 55308-4-0020-G9 D10.5*20L Axle 747S0-6-3771-N0 D25*180.5L Flat washer 55108-1-2520-FA D25*D8.5*2T Buffer 739S0-6-1081-B0 D27*D8.2*2.5T Front water bottle holder 749S0-6-2091-B0 189*154.2*67.9 Rear water bottle holder 749S0-6-2092-B0 203.1*189*157.4 Water bottler holder 747S0-6-2074-B0 113*138.3*120.5...
- Page 40 C clip 55540-3-0018-D0 S-40(1.8T) D40 Bushing 58002-6-1109-UC0 D25*D20*5.5L Cross bolt 52606-2-0015-F0 M6*1*15L Upper computer cable 747G0-6-2572-00 300L Middle computer cable 734G0-6-2587-00 1000L Lower computer cable 749G0-6-2573-00 2050L Sensor cable 805S0-6-2576-00 500L Round magnet 174R4-6-2574-00 Lower cable for quick key(1) 747S0-6-2544-00 850L Lower cable for quick key(2) 747S0-6-2536-00...
-
Page 41: Exploded Drawing
Exploded Drawing... -
Page 42: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 43 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
-
Page 44: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 45 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
- Page 46 Notes X10.5...
- Page 48 Crosstrainer X10.5 Pro...
