Assembly and Operating Instructions
max. 180 kg
~ 90 Min.
127 kg
L 211 | W 82 | H 188
TFFX105.01.03
Art.-No. TF-FX105
Crosstrainer
FX10.5 Pro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crosstrainer FX10.5 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taurus Crosstrainer FX10.5 Pro

Summary of Contents for Taurus Crosstrainer FX10.5 Pro

  • Page 1 Assembly and Operating Instructions max. 180 kg ~ 90 Min. 127 kg L 211 | W 82 | H 188 TFFX105.01.03 Art.-No. TF-FX105 Crosstrainer FX10.5 Pro...
  • Page 2 FX10.5...
  • Page 3 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 4 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.

  • Page 5: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button functions Powering on the crosstrainer Standby mode MANUAL (Manual programs) 3.5.1 Quick-Start program 3.5.2 Target programs PROGRAM (Profile programs) USER (User defined program) H.R.C.
  • Page 6 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT FX10.5...

  • Page 7: General Information

    GENERAL INFORMATION Technical Data LCD Display: Training duration in min. Speed in km/h Training distance in km Calories in kcal Incline Heart rate (using the hand pulse sensors or a chest strap) Watts Brake system: Electro-magnetic induction brake Resistance levels: Wattage Adjustable range in the watt programme: 10-350 W...

  • Page 8: Personal Safety

    Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 9: Electrical Safety

    Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 10: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 11: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...

  • Page 12: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembling the front and rear feet Screw the frontal foot (2) to the main frame (1) with two hexagonal screws (3), two hexagonal...
  • Page 13 Step 2: Assembling the console mast Connect the console cable in the mast (101) with the console cable in the main frame (102). Connect the signal cable in the mast (178) with the signal cable in the main frame (179). ࣑...
  • Page 14 Step 3: Mounting the arms Screw the left arm (12L) onto the console mast (11) with two Allen screws (6). Screw the right arm (12R) onto the console mast (11) with two Allen screws (6). Only hand tighten the screws in place. M8*1.25*20L step3 FX10.5...
  • Page 15 Step 4: Mounting the pedals Mount the right and left pedal poles (14R/14L) on their respective sides of the main frame (1), each with two washers (73), one Allen screw (72) and one locking nut (74) (see fig. 4-1). Mount the right and left pedal mounts (15R/15L) on their repsective arm (12R/12L), each with two washers (73), one Allen screw (72) and one locking nut (74) (see fig.
  • Page 16 Step 5: Mounting the handles Screw the right and left handles (13R/13L) onto the respecitve arm (12R/12L), each with three curved washers (9), three Allen screws (8) and three locking nuts (10) (see figs. 5-1 & 5-2). Only hand tighten the screws in place.
  • Page 17 Step 6: Mounting the console Connect the console cable from the console (100) with the console cable from the console mast (101) (see fig. 6-1). Connect the first hot-key cable from the console (106) with the first hot-key cable from the console mast (108) and the second hot-key cable from the console (107) with the second hot- key cable from the console mast (109) (see fig.
  • Page 18 Step 7: Mounting the covers Screw the front cover (99) under the console (19) onto the console mast (11) with two screws (96) and hand tighten the screws in place. Clip the rear cover (98) onto the front cover (99) (see fig.
  • Page 19 ST4.2*15L M5*0.8*12L step7...
  • Page 20 Step 8: Adjusting the feet The crosstrainer can be stabilised on un-even surfaces with the adjustable feet. Lift up the crosstrainer on one side to gain access to the adjustable feet underneath the frame. Turn the screw clockwise to unscrew the foot, lifting the crosstraining at that point.

  • Page 21: Operating Instructions

    OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console display DISPLAY DESCRIPTION Display of the elapsed training time (0:00 - 99:59) TIME Set a target time with the rotary knob (0:00 - 99:00) in 1 min.

  • Page 22: Button Functions

    Button functions BUTTON DESCRIPTION Increasing the setting value or resistance level Rotary knob Decreasing the setting value or resistance level Setting confirmation BODY FAT Body fat test RECOVERY Heart rate test on your recovery condition Returns you to the previous training mode while making settings or RESET selecting an option.

  • Page 23: Powering On The Crosstrainer

    Powering on the crosstrainer The console starts automatically as soon as the crosstrainer is plugged into the mains supply. Various components will light up. Choose a user profile (U1 - U4). Enter in your gender (SEX), age (AGE), height (HEIGHT) and weight (WEIGHT). You will proceed onto the main menu.

  • Page 24: Manual (Manual Programs)

    MANUAL (Manual programs) Under MANUAL you can choose between the Quick-Start program and one of the target programs. For target programs, settings for time (TIME), distance (DISTANCE), caloires (CALORIES) or heart rate (PULSE) are possible. 3.5.1 Quick-Start program In the main menu, select MANUAL and confirm your choice with a single push of the rotary knob.

  • Page 25: Program (Profile Programs)

    Training with multiple target values In the main menu select MANUAL and confirm your choice with a single push of the rotary knob. Select your target value for time, calories, distance and/or heart rate with the rotary knob and confirm your choice with a single push of the rotary knob. ⚠...
  • Page 26 FX10.5...

  • Page 27: User (User Defined Program)

    USER (User defined program) There are 16 segments available in user defined programs. In the main menu select USER and confirm your choice with a single push of the rotary knob. Select the resistance level of each segment and confirm each value with a single push of the rotary knob.

  • Page 28: Heart Rate Controlled Programs)

    H.R.C. (Heart rate controlled programs) WARNING ⚠ This crosstrainer is not medical equipment. The heart rate measurement of the crosstrainer can be unprecise. Different factors can influence the heart rate reading. The heart rate readings are only meant as a guide for training. There are three heart rate programs available to choose from.

  • Page 29: Watt (Watt Program)

    WATT (Watt program) In the main menu select WATT and confirm your choice with a single push of the rotary knob. Using the rotary knob, select a Watt value and confirm your setting with a single push of the rotary knob. NOTICE The pre-set value is 120.

  • Page 30: Body Fat (Body Fat Analysis)

    3.11 BODY FAT (Body fat analysis) Choose your user profile (U1-U4). To start the body fat analysis, in the main menu press the BODY FAT button and hold on to the hand pulse sensors. NOTICE Should you not properly grip the hand pulse sensors, the display will show the error code E-1. NOTICE If you wish to prematurley end the body fat analysis and return to the previous program, press the BODY FAT button again.

  • Page 31: Bluetooth And Fitness Apps

    3.12 Bluetooth and fitness apps This console is equipped with a bluetooth interface. Please take note that your mobile device needs to be compatible with the bluetooth interface of the treadmill (bluetooth 4.0). To use training apps you will have to activate the bluetooth function on your mobile device (tablet or smart phone) and start the fitness app.

  • Page 32: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠...

  • Page 33: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 34: Error Codes And Troubleshooting

    Error codes and troubleshooting The electronics of the crosstrainer are continually running tests. In case of deviations, an error code is shown on the display and normal operation is stopped for your safety. No values were received during the body fat analysis. Make sure that, during the analysis, you hold on to the hand pulse sensors with both hands.

  • Page 35: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Slide rails* Lubrication of slide rails and moving parts*...

  • Page 36: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape.

  • Page 37: Ordering Spare Parts

    Maximum weight/max. Benutzergewicht: Class/Klasse: Date/Datum: Sport-Tiedje GmbH, Flensburger Str. 55, 24837 Schleswig MADE IN Serial nº.: Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Cross-Elliptical Trainer Model Name: FX10.5 Pro Article Number: TF-FX105...

  • Page 38: Parts List

    Parts List Name Supplier Part No. Specification Qty. Main frame 747S1-3-1000-BA2 Front stabilizer 747S0-3-2100-BA1 Hex bolt M8*1.25*120L 50108-5-0120-F5 Spring washer D15.4xD8.2x2T 55108-2-1520-FA Hex bolt M8*1.25*70L 50108-5-0070-F4 Allen bolt M8*1.25*20L 54008-5-0020-F0 Flat washer D16*D8.5*1.2T 55108-1-1612-FA Allen bolt M8*1.25*50L 50308-5-0050-F3 Curved washer D22xD8.5x1.5T 55108-3-2215-FA Nylon nut...
  • Page 39 Left chain cover 734.4*878.2*98.1 747S0-6-4501-B0 Right chain cover 734*878.2*105.2 747S0-6-4502-B0 Left front chain cover 459.7*225.5*87.2 747S0-6-4529-B1 Right front chain cover 459.7*225.5*93.8 747S0-6-4530-B1 Front decorative cover 168.9*175.2*170.8 747S0-6-4523-B0 Upper decorative cover 639*313.7*176.5 747S0-6-4520-B0 Rear decorative cover 217.5*177.1*144.6 747A2-6-4521-B0 Round cover D632.9*36.7 747S0-6-4506-B0 Side cover 148*130.3*16.1...
  • Page 40 Moving wheel D70*43 73800-6-3886-B3 Bearing 6002 ,2RS,SKF 58006-6-1043-00 Moving wheel cover 162*136.2*87 747S0-6-3897-B0 Front handlebar protective cover(black) 240.5*127.8*59 747S0-6-3780-B0 Rear handlebar protective cover(black) 240.5*127.8*50 747S0-6-3781-B0 Bearing 6004 ,2RS,SKF 58006-6-1052-00 Sleeve(2) D25.4*D20.2*44L 747S0-6-2788-00 Front foot cover(left)(black) 152.3*91.1*46.7 747S0-6-3775-B0 Front foot cover(right)(black) 152.3*91.1*60 747S0-6-3776-B0 Bushing...
  • Page 41 Nylon nut M8*1.25*8T 55208-1-2008-CA Cross screw ST4.2*15L 52842-2-0015-F0 Cross bolt M5*0.8*12L, 52605-5-0012-F0 Computer bracket(front) 196.4*109.5*49.1 747S0-6-2592-B0 Computer bracket(rear) 196.3*109.5*96.4 747S0-6-2593-B0 Upper computer cable 300L 747S0-6-2572-00 Middle computer cable 900L 747S0-6-2587-00 Lower computer cable 1050L 747S0-6-2573-00 Connecting cable 350L 820S0-6-3177-00 Sensor cable 500L 805S0-6-2576-00 Round magent...
  • Page 42 Rear cover 766.7*169.6*144.3 747A2-6-4514-B0 D6*26.5*7.7 71600-6-4586-60 Cross screw ST4*1.41*12L 52804-2-0012-F0 Rear stabilizer 747A2-3-2112-BA2 Hex bolt M8*1.25*55L 50108-5-0055-F3 Hex bolt M8*1.25*35L 50108-5-0035-F3 Buffer D20*10L*M8*1.25 55308-4-0010-BB Bushing D19.15x(D25.6x32) 58002-6-1051-B0 xL(17+3) Allen bolt M8*1.25*20L 50308-5-0020-UF0 Sliding beam 747A2-3-5100-BA4 Ball cap D38*31L 55338-1-0031-B8 Square cap 25*50*12L 55312-2-2550-B8 Incline...

  • Page 43: Exploded Drawing

    Exploded Drawing...

  • Page 44: Warranty

    WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 45 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.

  • Page 46: Contact

    CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
  • Page 47 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
  • Page 48 Notes FX10.5...
  • Page 49 Notes...
  • Page 50 Notes FX10.5...
