Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Turning On and Setting the Equipment Programmes 3.4.1 Manual Programme (MANUAL) 3.4.2 Pre-Set Profile Programmes (PROGRAM) 3.4.3 Watt-controlled Programmes (WATT) 3.4.4 User-defined Programme (PERSONAL) 3.4.5 Heart rate oriented Programmes (HRC)
Page 4
ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT...
Page 5
With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
Page 6
ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
GENERAL INFORMATION Technical Data LED display of speed in km/h cadence (rotations per minute) training time in min training distance in km calories burnt in kcal heart rate (when using the hand sensors or a chest strap) Watts/Resistance level Resistance system: Electronic magnet brake system Resistance levels: Watt:...
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...
Page 13
Screws and tools Step 1: 5/16“ x 15mm M5 x 10mm 5/16“x 23 x 1.5T 5/16“x 23 x 2T curved screw (70) 6x screw (78) 4x washer (97) 4x washer (102) 2x (pre-mounted on the back of the console) Step 2: 5/16“...
The assembly can also be found as a video under the following link: https://www.sport-tiedje.co.uk/taurus-elliptical-cross-trainer-x7.1-tf- x7.1#product-assembly. To go directly to the assembly video, you can alternatively scan the QR code. (The video shows the X7.1, which assembly is identical to the X7.1-2)
Page 15
Step 2: Assembly of the console mast Move the console mast cover (41) as far as possible on the console mast (10). NOTICE Make sure that the console mast cover (41) points in the correct direction. On the upper opening of the frame (1), you will find a console cable (32). Unwind the console cable (32) and smooth it out in order to then thread it from the bottom to the top through the console mast (10).
Page 16
Step 3: Assembly of the handles Fasten the two washers (101) on the right and left side of the handle axles. Slide the lower left and right side of the handles (4 and 5) on the corresponding side of the axle. Place the two flat washers (97) on the two hexagonal screws (70) and fasten them on the thread holes on the end of the axle.
Page 17
Step 4: Assembly of the connecting arms Align the hole on the end of the connecting arm (L (7) and R (8)) with the hole in the bracket for the lower handles (L (4) and R (5)). The end of the bar should be in the bracket from the lower handles (L (4) R (5)).
Page 18
Step 5: Assembly of the covers Mount the covers for the connection arms (L (59) and R (60)) through the connection between the end of the bar and the lower handles (L (4) and R (5)) with four screws (79) and two screws (84).
Page 19
Step 6: Alignment of the feet If the floor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display CALORIES Display of the calories burned (0-999) TIME Display of training time in minutes (00:00–99:59) SPEED...
Button Functions Increasing the setting value ENCODER (+/-) Decreasing the setting value Select programmes MODE Button to confirm settings RECOVERY Heart rate test on your recovery condition RESET Resets all values START/STOP Starts and stops your training Turning On and Setting the Equipment Plug the adapter into the socket.
Programmes In the main menu you can choose from the different programmes: MANUAL (Target programmes) PROGRAM (Profile programmes) PERSONAL (User defined programme) H.R.C (Heart rate controlled programmes) WATT (Watt programme) Use the encoder to select one of the programmes: Manual, Program, Fitness, Watt, Personal or H.R.C. Confirm the programme with the MODE button.
3.4.2 Pre-Set Profile Programmes (PROGRAM) You have 12 default programmes to choose from (P1-P12). In the main menu select PROGRAM and confirm the selection by pressing the MODE button. Select one of the programmes P1-P12 with the encoder and press MODE to confirm. Set the resistance level, time, distance, calories and/or pulse with the encoder.
3.4.4 User-defined Programme (PERSONAL) In the main menu select PERSONAL and confirm the selection by pressing the MODE button. NOTICE There are 16 segments available in user defined programmes. Set a resistance level for each segment and press MODE to confirm. Press START/STOP to begin the workout During the training, the resistance level can be adjusted with the encoder.
RECOVERY - Recovery Frequency This function measures how fast your heart rate recovers after a training session. The faster your heart rate recovers, the better your fitness level. A 60 second countdown will start when you press the recovery button. Hold the hand pulse sensors with both hands and do not train as long as the countdown is running.
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.
Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display strap Reposition chest...
DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols.
ORDERING SPARE PARTS Serial Number and Model Name In order to provide you with the best possible service, please have the model name, article number, serial number, exploded drawing and parts list ready. The corresponding contact options can be found in chapter 10 of this operating manual. NOTICE The serial number of your equipment is unique.
Parts List Name Qty. Name Qty. Main Frame 600m/m_DC Power Cable Pedal Arm (L) Gear Motor Pedal Arm (R) 350m/m_Sensor W/Cable Lower Handle Bar (L) 850m/m_Handpulse W/Cable Assembly Lower Handle Bar (R) 37~4 Ø3 × 20m/m_Tapping Screw Bushing Housing, Pedal Arm Power Adaptor Connecting Arm (L) Slide Wheel , Urethane...
