4. Hardware Installation

Because there are large differences between computers, we can give you only a general
installation guide. Please refer your computer's reference manual whenever in doubt.
1. Mount the EX-1580SHMVS on a wall or DIN-Rail if required.
2. Connect the USB cable to the USB-B port on the hub.
3. Connect the optional power supply to the terminal block on the hub.
4. Connect the other end of the USB cable (USB-A connector) to the USB-A port on your PC.

5. Driver Installation

All Operating Systems
After the hardware installation the OS will recognize the device automatically and install the
drivers.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „Ports (COM & LPT)" & „USB-Controller" the
following new entry's:
© Copyright 2024 by EXSYS Vertriebs GmbH. All Rights Reserved
DIN-Rail mount
13
English
Holes for
wall installation
