3. Layout, Connections & Jumpers
3.2 Connections
USB 3.2 Gen 1 B-Port:
GND_DRAIN
StdB_SSTX +
StdB_SSTX -
D-
D+

3.3 Jumper Settings

The EX-1580SHMVS will be delivered with the setting USB-Bus-Power.
bility to cut the power at the data line.
sides. Then you must set the jumper JP1 from ENA (Enable) to DIS (Disable). See the following
picture.
JP1
DIS
ENA
© Copyright 2024 by EXSYS Vertriebs GmbH. All Rights Reserved
StdB_SSTX+
StdB_SSTX -
VBus
GND
For this you open the case with the eight screws on both
ATTENTION!
Never plug in with force or in wrong direction.
