Cypress Semiconductor CY7C1141V18 Specification Sheet

Features
■ Separate Independent read and write data ports
❐ Supports concurrent transactions
■ 300 MHz to 375 MHz clock for high bandwidth
■ 4-Word Burst for reducing address bus frequency
■ Double Data Rate (DDR) interfaces on both read and write ports
(data transferred at 750 MHz) at 375 MHz
■ Read latency of 2.0 clock cycles
■ Two input clocks (K and K) for precise DDR timing
❐ SRAM uses rising edges only
■ Echo clocks (CQ and CQ) simplify data capture in high speed
systems
■
Single multiplexed address input bus latches address inputs
for both read and write ports
■ Separate Port Selects for depth expansion
■ Data valid pin (QVLD) to indicate valid data on the output
■
Synchronous internally self-timed writes
■
Available in x8, x9, x18, and x36 configurations
■ Full data coherency providing most current data
■ Core V = 1.8V ± 0.1V; IO V
DD
■ Available in 165-Ball FBGA package (13 x 15 x 1.4 mm)
■ Offered in both Pb-free and non Pb-free packages
■
Variable drive HSTL output buffers
■
JTAG 1149.1 compatible test access port
■ Delay Lock Loop (DLL) for accurate data placement
Configurations
With Read Cycle Latency of 2.0 cycles:
CY7C1141V18 – 2M x 8
CY7C1156V18 – 2M x 9
CY7C1143V18 – 1M x 18
CY7C1145V18 – 512K x 36
Selection Guide
Description
Maximum Operating Frequency
Maximum Operating Current
Note
1. The QDR consortium specification for V
= 1.4V to V .
DD
Cypress Semiconductor Corporation
Document Number: 001-06583 Rev. *D
18-Mbit QDR™-II+ SRAM 4-Word Burst
Architecture (2.0 Cycle Read Latency)
[1]
= 1.4V to V
DDQ DD
is 1.5V + 0.1V. The Cypress QDR devices exceed the QDR consortium specification and are capable of supporting V
DDQ
• 198 Champion Court
CY7C1141V18, CY7C1156V18
CY7C1143V18, CY7C1145V18

Functional Description

The CY7C1141V18, CY7C1156V18, CY7C1143V18, and
CY7C1145V18 are 1.8V Synchronous Pipelined SRAMs,
equipped with QDR™-II+ architecture. QDR-II+ architecture
consists of two separate ports to access the memory array. The
read port has dedicated data outputs to support read operations
and the write port has dedicated data inputs to support write
operations. QDR-II+ architecture has separate data inputs and
data outputs to completely eliminate the need to "turn-around"
the data bus required with common IO devices. Access to each
port is accomplished through a common address bus.
Addresses for read and write addresses are latched on alternate
rising edges of the input (K) clock. Accesses to the QDR-II+ read
and write ports are completely independent of one another. To
maximize data throughput, both read and write ports are
equipped with Double Data Rate (DDR) interfaces. Each
address location is associated
(CY7C1141V18), or 9-bit words (CY7C1156V18), or 18-bit words
(CY7C1143V18), or 36-bit words (CY7C1145V18) that burst
sequentially into or out of the device. Because data can be trans-
ferred into and out of the device on every rising edge of both input
clocks K and K, memory bandwidth is maximized while simpli-
fying system design by eliminating bus "turn-arounds".
Depth expansion is accomplished with Port Selects for each port.
Port Selects enable each port to operate independently.
All synchronous inputs pass through input registers controlled by
the K or K input clocks. All data outputs pass through output
registers controlled by the K or K input clocks. Writes are
conducted with on-chip synchronous self-timed write circuitry.
375 MHz 333 MHz
375 333
1020 920
,
• San Jose CA 95134-1709
with four 8-bit words
300 MHz Unit
300 MHz
850 mA
DDQ
• 408-943-2600
Revised March 06, 2008
