STEP 3
M3 x 8 DIN7984
Secure the water block with the provided mounting screws M3 x 8
SCREW
DIN7984. For each memory module, two (2) screws must be used.
Tighten the screws evenly using the Allen Key 2 mm.
For this step, you will need:
M3 x 8 DIN7984 Screw
Allen Key2mm
(2 pcs / 1 module)
STEP 3
FITTINGS AND TUBING
STEP 1
IN / OUT
Tighten the fittings in a clockwise direction until the gasket
underneath is compressed. The installation of the water block is now
IN / OUT
complete. The IN/OUT port is not explicitly prescribed.
EK recommends using EK fittings with all EK water blocks.
STEP 1
- 11 -
