Tektronix 2247A Operator's Manual page 162

Table 6-1 (cont)
CHARACTERISTICS
Line Voltage Range
Line Frequency
Line Fuse
Maximum Power
Consumption
POWER SOURCE
90 Vac to 250 Vac.
48 Hz to 445 Hz.2
2 A, 250 V, slow blow.2
100 Watts (155 VA).
CRT DISPLAY
Trace Rotation Range
Standard Phosphor
Y-Axis Orthogonality
Nominal Accelerating
Voltage
CH 2 Signal Out
Dynamic Range
Deflection Factor
-3dB Bandwidth
OC Offset (Adjusted)
A GATE Out
Output Voltage
Output Drive
P31.2
16 kv.4
OPTION 15
+7 divisions.
10 mV/div into 50.1
+ 10%.
20 mV/div into 1 MQ
+10%.
DC to 25 MHz.
< 0.5 div (measured
at 2 mV/DIV).
formance Check).
6-26
2247A Operators
Ne
