Sinexcel Izar 6-50P Plug User & Installation Manual page 2

IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING:
This manual contains important instructions for Izar.
Please always follow the following precautions when installing and using Izar especially
electric products are involved.
1. Read and follow all warnings and instructions before installing and operating
the charger. Install and operate only in accordance with the instructions.
Failure to do so may result in death, injury or property damage, which will void
the Limited Warranty.
2. Avoid fire risks, install Izar AC charging station only into circuits that are
equipped with overcurrent protection for branch circuits. The trip value of the
branch circuit breaker
SEA240/40I-U-14/14W/14Y
240/48I-U-H/HW/HY.
3. Before installing the Izar AC charging station, consult with a licensed
contractor, such as a licensed electrician, to ensure compliance with local
building and electrical codes and standards, climate conditions, safety
standards, and all applicable codes and ordinances. Only trained professionals
or experts are allowed to install your Izar AC charging station. Inspect the
charging station for proper installation before use.
4. Ensure the Izar AC charging station is grounded stably. Failure to ground the
charging station can lead to electrocution or fire. Izar AC charging station must
be grounded. lf it should malfunction or break down, grounding provides a path
of least resistance for electric current to reduce the risk of electric shock. For
cord connected model, Izar AC charging station is equipped with a cord having
an equipment grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances. For hard-wired model, Izar AC
charging station must be connected to a grounded, metal, permanent wiring
system, or an equipment-grounding conductor must be run with the circuit
conductors and connected to the equipment grounding terminal or lead on the
product.
5. Install Izar AC charging station on a surface that can support the weight of
the charging station. Failure to do so can result in death, personal injury, or
property damage. Inspect whether the charging station is properly installed
before use.
6. Do not put fingers into the electric vehicle connector.
7. When there are children nearby, this device should be supervised.
8. Do not use the charger in hazardous locations. Do not install it near
flammable, explosive, or combustible materials.
9. Do not use this product if the flexible input power cable or EV charging
cable is worn, has broken insulation, or any other signs of damage. Resort to
local customer support in these cases.
10. Do not use this product if the enclosure or the EV connector is broken,
cracked, open, or shows any other indication of damage. Resort to local
customer support in these cases.
11. Use 221˚F (105°C) wire copper conductors only.
12. Do not operate Izar in temperatures outside its operating range. For
charging stations set to 40A/48A, the range is -22˚F to +122˚F (-30˚C to
+50˚C).
Other than the charging cable, Izar contains no field serviceable parts. Do not
attempt to repair or service any other part of the unit yourself. If the unit
requires servicing, contact local customer support.
Ensure that the charging cable is properly positioned so that it cannot be
stepped on, tripped over, or subjected to damage or stress. Do not close a
garage door on the charging cable.
for SEA240/40I-U-6/6W/6Y
should be 50A, and
and
60A for SEA
responsibility to comply with all applicable
codes or safety standards. This document
describes the most commonly used installation
and mounting scenarios. If situations arise in
which it is not possible to perform an installation
following the procedures provided in this
document, contact Sinexcel Electric Co,. Ltd.
Sinexcel Co., Ltd is not responsible for any
damages that may occur resulting from custom
installations that are not described in this
document or for any failure to adhere to
installation recommendations.
WARNING:
Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
DANGER:
Caution of electricity.
Caution of fire.
NOTE:
A note gives more details to make use
easier.
It means that the machine cannot be
discarded after use and should be
delivered to a dedicated recycling
place, otherwise it may
environmental pollution.
Grounding identification:
This indicates that the product must
be grounded during installation. If it
is not properly grounded, it may cause
death or serious injury.
IMPORTANT:
Under no circumstances will
compliance with
information in this manual
relieve the user of his/her
cause
the
