Lockly VISION ELITE Installation Manual page 24

INSTALLATION OVERVIEW AND PARTS LIST
W
I
G
H
2x
X
N
P
L
Lockly Vision Elite can be fitted for both right swing doors and left swing doors.
™
D
E
F
2x
J
K
4x
E
B
A
C
V
S
Activation Card
SAVE
T
Need help? Email: help@Lockly.com | Support: +1(669) 500-8835
Parts List
Labeled As Description
A Keys
B Exterior Assembly
D Mounting Plate
E Adhesive
F PM5×60mm Screw
G Interior Assembly
H PM4*12MM Screw
I Battery Cover
J Deadbolt
K KA4*20MM Screw
L Strike Plate
N Dust Box
Strike Spacer
P
R Vision Connect
S LAN Cable
Power Plug
T
TF Card
U
V Activation Card
W KM3x6mm Screw
X Pin Key
R
U
