KT-3200
Kiosk
User Manual
13130900010 Ver. A0
http://www.posiflex.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KT-3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POSIFLEX KT-3200

Summary of Contents for POSIFLEX KT-3200

  • Page 1 KT-3200 Kiosk User Manual 13130900010 Ver. A0 http://www.posiflex.com...

  • Page 2: Table Of Contents

    Opening the Front of the Kiosk ................23 Parts and Components .................. 24 Locating the Power Supply Cable and the Internet Cable ........24 I/O Ports of the KT-3200 ..................24 Introduction to the PP-7600K ................25 Introduction to the CD-3601K ................29...

  • Page 3: General Information

    Introduction to the KT-3200 Packed functionality and convenience in an appealing design, the Apollo KT-3200 Series is a 32” self-service kiosk for quick service and fast casual restaurants. It serves as a seamless extension of the existing POS terminals, helping store owners drive sales during peak times, and offering various ways for consumers to order, pay and engage with the brand.
  • Page 4 Appearance (Bottom) Appearance (Pole and Base)
  • Page 5 Appearance (Top)

  • Page 6: Specifications

    Specifications Model KT-3230 KT-3250 Intel Skylake Core i3-6100U or Intel Bay Trail J1900 CPU Core i5-6300U DDR3L SO-DIMM slot x 1, DDR4 SO-DIMM slot x 2, Memory max. 8 GB max. 16 GB Storage Device SATA storage x1 (for 2.5" SSD / HDD) Intel vPro support Yes (for option) Yes (for option)

  • Page 7: Check List

     Proximity sensor (SU-100)…………………………..……………..(x1)  WIFI (dual band + BT, WF-66)………………………..…………...(x1)  NFC/RFID, Finger Print, MSR (CC-3000)……………..…………..(x1) Free Standing Installation Tool list In addition to the standard tools, the following tools are required to set up the kiosk system KT-3200:  Cross Screwdriver...

  • Page 8: Scope Of Delivery

    Scope of Delivery Before installing the KT-3200, confirm that you have 5 main parts in 3 boxes: 32-inch touch monitor Belly system unit Box A Accessory pack Pole mount Box B Box C Base plate...

  • Page 9: List Of Enclosed Accessories

    List of Enclosed Accessories User Manual, Recovery DVD, Paper Roll, and Accessory Pack (Belly System Key and 4 Screws (M5- 8L) for Monitor and Belly System) 4 Screws (M10x40L) and 2 Screws (#6/32-20L) for Base Plate 14 Screws (M5-8L) for Pole Mount...

  • Page 10: Step-By Step Installation

    Step-by Step Installation Then start to install the KT-3200 by referring to the step-by-step instruction given below. Confirm that the two screw holes of the small stand plate is well aligned with the two screw holes of the stand. Next, insert two screws into the screw holes on the small stand plate that will be directly attached to the stand.
  • Page 11 Confirm that the four screw holes of the large stand plate is well aligned with the four screw holes of the small stand plate. Next, insert four screws into the screw holes on the large stand plate that will be directly attached to the small stand plate.
  • Page 12 Align the four screw holes of each of the two wall side pillars with the four screw holes of the two sides of the stand. Next, insert screws into the screw holes. Then, fix the pair of wall side pillars tightly to the stand with the eight screws.
  • Page 13 Make each of the two gliding hooks on the back of the belly system unit glide along the stopper of each of the two wall side pillars until the gliding hooks are stopped by the stoppers. Gliding Stopped Turn key to the right to release and open the front door of the belly system unit.
  • Page 14 Install the touch monitor. Before mounting the monitor onto the belly system unit, hang the monitor onto the wall side pillar pair by gliding the left and right hooks of the monitor along the left and right guiding tracks of the wall side pillar pair. The monitor is well set down when being hit and stopped by the belly system unit.
  • Page 15 Fix the monitor to the belly system unit with screw bolts. Connect the LVDS cable, backlight cable, and USB cables to the main board. Make the power cord and LAN cable of the kiosk pass through the cable exit at the lower portion of the rear of the belly system unit for proper cable management.

  • Page 16: Dual Side Installation

    In addition to the standard tools, the following tools are required to set up the kiosk system KT-3200:  Cross Screwdriver Scope of Delivery Before installing the dual-side KT-3200, confirm that you have 8 main parts in 4 boxes: 32-inch touch monitor (x2)

  • Page 17: List Of Enclosed Accessories

    Pole mount Box B Box C Base plate List of Enclosed Accessories User Manual, Recovery DVD, Paper Roll, and Accessory Pack (Belly System Key and 4 Screws (M5- 8L) for Monitor and Belly System) 4 Screws (M10x40L) and 2 Screws (#6/32-20L) for Base Plate 14 Screws (M5-8L) for Pole Mount...

  • Page 18: Step-By Step Installation

    Step-by Step Installation Then start to install the dual-side KT-3200 by referring to the step-by-step instruction given below. 1. Confirm that the two screw holes of the small stand plate is well aligned with the two screw holes of the stand. Next, insert two screws into the screw holes on the small stand plate that will be directly attached to the stand.
  • Page 19 2. Confirm that the four screw holes of the large stand plate is well aligned with the four screw holes of the small stand plate. Next, insert four screws into the screw holes on the large stand plate that will be directly attached to the small stand plate.
  • Page 20 4. Align the four screw holes of each of the two wall side pillars with the four screw holes of the two sides of the stand. Next, insert screws into the screw holes. Then, fix the pair of wall side pillars tightly to the stand with the eight screws.
  • Page 21 6. Make each of the two gliding hooks on the back of the belly system unit glide along the stopper of each of the two wall side pillars until the gliding hooks are stopped by the stoppers. Gliding Stopped 7. Turn key to the right to release and open the front door of the belly system unit.
  • Page 22 9. Install the touch monitor. Before mounting the monitor onto the belly system unit, hang the monitor onto the wall side pillar pair by gliding the left and right hooks of the monitor along the left and right guiding tracks of the wall side pillar pair.
  • Page 23 11. Fix the monitor to the belly system unit with screw bolts. 12. Connect the LVDS cable, backlight cable, and USB cables to the main board. 13. Make the power cord and LAN cable of the kiosk pass through the cable exit at the lower portion of the rear of the belly system unit for proper cable management.

  • Page 24: Enclosure Overview

    14. Close the front door of the belly system unit. 15. Repeat step 5 through step 14 to complete installing the belly system unit and touch monitor onto the other side of the KT-3200. Enclosure Overview Full Unit – Locked with Keys...

  • Page 25: Opening The Front Of The Kiosk

    Opening the Front of the Kiosk Turn key to the right. The front door is released and opens a little. Released and open. Pull the front door. This is the service access for the printer and the scanner.

  • Page 26: Parts And Components

    Locating the Power Supply Cable and the Internet Cable You can find where the power supply cable and the Internet cable on the rear side of the kiosk. To power on the KT-3200, just plug the power supply cable to a wall plug.

  • Page 27: Introduction To The Pp-7600K

    Introduction to the PP-7600K Front View Power Button (Disabled) Power LED Indicator Paper-out LED Indicator Error LED Indicator Feed Button Cover Open Lever Paper Cover Paper Roller Wedge Groove Paper Exit Paper Near End Sensor Part Names Description Power LED Indicator This indicator turns on when the printer is on.
  • Page 28 Loading a Paper Roll Before loading a paper roll, make sure you use a specified paper type. Follow the steps below to load a paper roll. Press down the cover open lever to release the paper cover. The paper cover ejects. Then, open the paper cover manually.
  • Page 29 Next, set the paper width by using PP-7600K Series thermal Printer Software Switch Utility for Windows. The software switch utility can be downloaded from the Posiflex’ global website: http://www.posiflex.com/en-global/Download/download. To get more detailed information on the paper width jumper setting, contact directly the Posiflex’...
  • Page 30 Error LED indicator is flashing Power off the printer; after 10 seconds, power it back on. If the error LED indicator turns on again even after turning the power back on, malfunction may occurs. Contact your dealer or Posiflex’ technical service team.

  • Page 31: Introduction To The Cd-3601K

    Introduction to the CD-3601K Scan Window w/ Object Detector Beeper Hole Interface Cable Connector Checking Firmware Version To check the firmware version of the scanner, please scan the QR code shown at the right side. Scanner Maintenance The scanner is designed for long-term trouble-free operation and rarely requires any maintenance.
  • Page 32 Problem Diagnostic Tips A stray barcode is sitting somewhere in the scanner field of view. Remove all barcode labels from the scanner’s scan volume and try again. The scanner cannot send the data to the terminal system. Make sure that the scanner is installed well and your host terminal is ready to receive data.
  • Page 33 USB-HID USB-VCP Buzzer Settings Disable buzzer Enable buzzer Buzzer loudness: Loud...
  • Page 34 Green Aiming Detection Warm White Illumination Detection No Illumination Detection To do advanced settings of the scanner, download the CD-3601K user manual from Posiflex Global Website: (http://www.posiflex.com/en-global/Download/download).

  • Page 35: Introduction To The Cc-3000

    Before installing the drivers of the CC-3000 card reader, power on the KT- 3200 kiosk. Installing and Starting the Posiflex USB MSR Manager 1. Before installing the USB MSR Manager, please visit Posiflex official website (http://www.posiflex.com/en-global/Download/download) to download the utility.
  • Page 36 1. If you purchase the attachment having the RFID module of which the interface is Virtual COM, install the RF-3X0 Virtual COM Driver before installing the RF-3X0 Setup Tools. Please visit Posiflex official website (http://www.posiflex.com/en-global/Download/download) to download the virtual COM driver.
  • Page 37 Setup Tool installation. 2. Then, follow the step-by-step instructive messages to complete the virtual COM driver installation. 3. Please visit Posiflex official website (http://www.posiflex.com/en- global/Download/download) to download the RF-3X0 Setup Tools. 4. Then, follow the step-by-step instructive messages to complete the tool installation.
  • Page 38 Checking the LED status: Standby status: solid blue Reading Status: solid blue and solid red (The red LED will be off after around 2 seconds.) To do advanced settings of the scanner, download the CC-3000 user manual from Posiflex Global Website: (http://www.posiflex.com/en-global/Download/download).

This manual is also suitable for:

Kt-3230Kt-3250
