3 Installation
moog
ID no.: CB08759-001 Date: 03/2023
Plug 1
Pin no.
1 SYNC IN-
2 SYNC OUT-
3 GND
4 RX+
5 TX+
6 SYNC IN+
7 SYNC OUT+
8 RX-
9 TX-
Table 3.2: TWINsync connecting cable plug/pin assignment
Plug 2
Cable
Pin no.
SYNC OUT- 2
SYNC IN- 1
GND 3
TX+ 5
RX+ 4
SYNC OUT+ 7
SYNC IN+ 6
TX- 9
RX- 8
Specification TWINsync module

3.2 TWINsync connecting cable technical data

TWINsync connecting cable
Article designation
Cable length
Connections
Cross-section
Table 3.3: Connecting cable technical data and article description
11
CB36987-xxx-yyy
1 m
2 x SUB-D 9-pin male
4 x 2 x 0.25 + 2 x 0.50
