Summary of Contents for Kontron CG2100

  • Page 1 Kontron CG2100 Carrier Grade Server Document Revision 1.2...

  • Page 2: Revision History

    Disclaimers Copyright © 2010 Kontron AG. All rights reserved. All data is for information purposed only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate; however, no responsibility is assumed for inaccuracies. Kontron and the Kontron logo and all other trademarks or registered trademarks are the property of their respective owners and are recognized.

  • Page 3: Table Of Contents

    Revision History .......................2 1. Introduction ......................9 2. System Overview ....................10 Introduction ....................10 2.1.1 Kontron CG2100 Carrier Grade Server ............10 2.1.2 CG2100 Server Feature Summary ............. 11 CG2100 Server External Chassis Features ..........14 2.2.1 Chassis -- Front Views ................14 2.2.2...
  • Page 4 Introduction ....................55 SAS/SATA Control Module Features ............56 SAS/SATA Control Module Block Diagram ..........56 SAS/SATA Control Module Functional Description........56 7.4.1 SAS Features ..................... 56 7.4.2 SATA Features ................... 56 SAS/SATA Control Module Flex Cable Connector ........57 www.kontron.com...
  • Page 5 10. USB SD Flash Module ................... 73 10.1 Introduction ....................73 10.2 USB SD Flash Module Features ..............74 10.3 USB SD Flash Module Connector Specifications ........74 10.3.1 USB Connector ................... 74 10.3.2 SD Card Connector ..................75 www.kontron.com...
  • Page 6 AC Power Supply Air Flow ................96 14.5 AC Power Supply Thermal Protection ............96 15. Regulatory Specifications ..................97 15.1 Safety Compliance ..................97 15.2 Electromagnetic Compatibility ..............97 15.3 CE Mark ...................... 97 15.4 NEBS Compliance ..................97 Appendix A: Glossary ....................99 www.kontron.com...
  • Page 7 List of Figures Figure 1. Kontron Carrier Grade Server CG2100 (Top Covers On) ....... 10 Figure 2. Kontron CG2100 Carrier Grade Server (Covers and Front Bezel Removed) 11 Figure 3. CG2100 Server Block Diagram ............... 13 Figure 4. Front View of the CG2100 Server (Bezel Installed) ........14 Figure 5.
  • Page 8 Figure 55: Power Distribution Board ................86 Figure 56: PDB Input Connector ..................87 Figure 57 PDB Baseboard Card Edge Connector Mechanical Drawing ......89 Figure 58. AC Power Supply Module Mechanical Drawing ..........93 Figure 59: AC Power Supply Module Output Connector ..........93 www.kontron.com...

  • Page 9: Introduction

    Introduction This document provides detailed information about the Kontron CG2100 Carrier Grade Server, including information about the chassis hardware, cables, connectors, system boards, power subsystem, and regulatory requirements. This document is organized into the following chapters: Chapter 1: Introduction Provides an overview of this document...

  • Page 10: System Overview

    Kontron CG2100 Carrier Grade Server Technical Product Specification System Overview This chapter provides an overview of the key features of the Kontron CG2100 Carrier Grade Server in the following sections: Section 2.1: Introduction Provides an overview of the server features and a block diagram of the Kontron CG2100 Carrier Grade Server Section 2.2:...

  • Page 11: Cg2100 Server Feature Summary

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 2. Kontron CG2100 Carrier Grade Server (Covers and Front Bezel Removed) Item Description Item Description PCI riser options: 3x PCIe, 5x PCIe butterfly, or 2x SD flash modules PCI-X +3x PCIe butterfly...
  • Page 12 Integrated Baseboard Management Controller (Integrated BMC), IPMI 2.0-compliant Integrated Super I/O on LPC interface The CG2100 T5520UR server board is mounted horizontally toward the rear of the chassis behind the CPU/memory area fan array. Up to six 2.5-inch hot-swappable SAS/SATA technology hard drives can be mounted in the drive bays, which are accessed from the front of the chassis with the front bezel removed.

  • Page 13: Figure 3. Cg2100 Server Block Diagram

    OEM industrial design requirements. The bezel has to be removed to access the drive carriers in the hard drive bays and the optional SD flash modules. Figure 3 shows a block diagram of the CG2100 server I/O subsystems. Figure 3. CG2100 Server Block Diagram www.kontron.com...

  • Page 14: Cg2100 Server External Chassis Features

    Chassis -- Front Views Figure 4 Figure 5 shows the front of the CG2100 server with the bezel installed. shows the front of the server with the bezel removed. Removing the bezel provides access to the hard drive bays and SD card modules.

  • Page 15: Front Panel

    2.2.3 Hard Drives The CG2100 Carrier Grade Server chassis supports up to six hard disk drives in the drive bays, which are accessible from the front of the chassis. SAS or SATA 2.5-inch hard disk drives are mounted in removable drive carriers (Figure 7, “A”) that latch into the drive bay sub-assembly. The hard disk drives installed in the carriers are hot-swappable.

  • Page 16: Chassis -- Rear View

    Each hard drive used in the server must be mounted to a drive carrier (A) using four screws (B) inserted into the sides of the drive as shown in Figure 8. Figure 8: SAS/SATA Hard Drive Tray Assembly 2.2.4 Chassis -- Rear View Figure 9 shows the rear of the CG2100 Server chassis. www.kontron.com...

  • Page 17: Cg2100 Server Internal Features

    CG2100 Server Internal Features 2.3.1 Intel® T5520UR Server Board (the Baseboard) See the Intel® S5520UR Server Board Technical Product Specification on the Kontron website NOTE: for detailed information about the baseboard used in this server. Figure 10 T5520UR Server Board...

  • Page 18: Pci Riser Card Assembly

    Kontron CG2100 Carrier Grade Server Technical Product Specification 2.3.2 PCI Riser Card Assembly The PCI riser card assembly houses one of three different PCI riser card options, as defined in Chapter 11, “PCI Riser Card Assembly”. One of the three riser cards, along with the appropriate PCI adapter cards, is assembled into the sheet metal housing when the assembly is removed from the chassis.

  • Page 19: Cooling Subsystem

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 12. Riser Card Configurations 2.3.3 Cooling Subsystem All system components except the power distribution board and power supplies are cooled by a set of fans mounted near the middle of the chassis behind the front panel board, as shown in Figure 13...

  • Page 20: Figure 13. Cooling Subsystem

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 13. Cooling Subsystem The CG2100 server has redundant six-fan cooling with four 80x38mm fans and two 60x38mm fans. There are three main cooling zones, as shown in Figure 13: • Zone 1 (blue) contains fans 1 and 2, which cool CPU1 and all the components in this zone.

  • Page 21: Cg2100 Server Platform Management Subsystem

    Kontron CG2100 Carrier Grade Server Technical Product Specification • Up to two processors • 96 Gbytes of DDR3 DIMM memory • Six hard drives • Five PCI cards The cooling subsystem meets acoustic and thermal requirements at the lower fan speed settings. At the higher fan speed settings, thermal requirements are met for the maximum ambient temperatures, but acoustic requirements are not met.

  • Page 22: Non Ipmi Features

    CG2100 Server Specifications This section lists the environmental and physical specifications for the CG2100 server. 2.5.1 Environmental Specifications The CG2100 server is designed and tested to meet the environmental specifications in Table 2. : Environmental Specifications Summary Table 2 Environment...

  • Page 23: Physical Specifications

    K00158 CRMS Environmental Standards Specification RoHS Complies with RoHS Directive 2002/95/EC and RoHS 6/6 2.5.2 Physical Specifications Table 3 describes the physical specifications of the CG2100 system. Table 3. Physical Dimensions & Weight (Max) Height 3.45 inches (87.6 mm) Width 17.14 inches (435.3 mm)

  • Page 24: Cables And Connectors

    Kontron CG2100 Carrier Grade Server Technical Product Specification Cables and Connectors This chapter describes interconnections among the various components of the Kontron CG2100 Carrier Grade Server with overview diagrams as well as tables describing the signals and pin-outs for ®...

  • Page 25: Figure 14: Cg2100 Server Interconnect Block Diagram

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 14: CG2100 Server Interconnect Block Diagram www.kontron.com...

  • Page 26: Cable And System Interconnect Descriptions

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 4 System Cables Cable Number and Name End 1 Connection End 2 Connection End 3 Connection 1: Power distribution Power distribution board SAS/SATA backplane Front panel board 2: Flex Circuit / Bridgeboard Assembly...

  • Page 27: Led/Switch Board Power And Signal Cable

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 16. Flex Circuit/Bridgeboard Assembly 3.2.3 LED/Switch Board Power and Signal Cable The LED/switch board power and signal cable connects the LED/switch board to the front panel board. Figure 17shows the physical details of the LED/switch board cable.

  • Page 28: 60Mm Fan Power Cable

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 18. 80mm Fans Power and Signal Cable Mechanical Drawing 3.2.5 60mm Fan Power Cable The 60mm fan power cable connects the PCI cooling fans to the front panel board. The physical details of the 60mm fan cable are shown in Figure 19 www.kontron.com...

  • Page 29: Serial Port Cable

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 19. 60mm Fan Power and Signal Cable Mechanical Drawing 3.2.6 Serial Port Cable The serial port cable provides the interconnection between the user-accessible RJ45 serial port connector on the front panel board and the baseboard. The physical details of the serial port cable are shown in Figure 20.

  • Page 30: Tam Front Panel Cable

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 20. Serial Port Cable Mechanical Drawing 3.2.7 TAM Front Panel cable The TAM (Telco Alarms Module) front panel cable connects the Telco alarm signals between the TAM and the front panel board. The physical details of the TAM front panel cable are shown in Figure 21 TAM Front Panel Cable Mechanical Drawing.

  • Page 31: Alarms Cable

    Kontron CG2100 Carrier Grade Server Technical Product Specification Cable Mechanical Drawing Figure 22 USB SD Flash 3.2.9 Alarms Cable The alarms cable runs from the rear sheet metal panel of the system and connects to the TAM (Telco Alarms Module). The physical details of the alarms cable are shown in Figure 23 below.

  • Page 32: Video Port Connector

    Universal Serial Bus (USB) Interface The CG2100 server provides five externally accessible USB ports. Four ports are provided in the rear of the system and the one on the front panel is accessible without removing the front bezel The built-...

  • Page 33: Ethernet Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification in USB ports permit the direct connection of five (one front, four rear) USB peripherals without an external hub. If more devices are required, an external hub can be connected to any of the user accessible built-in ports.
  • Page 34 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 6: NIC Status LED LED Color LED State NIC State Green/Amber (Left) 10Mbps Green 100 Mbps Amber 1000 Mbps Green (Right) Active Connection Blinking Transmit / Receive activity www.kontron.com...

  • Page 35: Front Panel Board

    Kontron CG2100 Carrier Grade Server Technical Product Specification Front Panel Board This chapter provides an overview of the Kontron CG2100 Carrier Grade Server Front Panel (FP) board and includes information on board hardware, connectors, power subsystem, optional add-ins, and regulatory requirements. This chapter is organized into the following sections: Section 4.1:...

  • Page 36: Front Panel Board Features

    USB flash drive support. Most signals pass from the front panel interface off the baseboard directly to the appropriate device (switch, LED, etc). Figure 28 shows the FP board components. Figure 28. CG2100 Server FP Board Layout (Primary Side) Item Description...

  • Page 37: Front Panel Board Functional Description

    FP board. Front Panel Board USB Ports There are three USB channels on the CG2100 server FP board. One is used by the SMART* Embedded USB Solid-State Drive, the second is used by the SD flash module, and the third is used as an external USB port accessible through the combo RJ45/USB connector on the front of the chassis.

  • Page 38: Front Panel Board Fan Controller

    Kontron CG2100 Carrier Grade Server Technical Product Specification This serial port requires a special cable to enable the port from the baseboard. The cable must provide a ground to connector pin 5 to enable the serial port to the front panel connector.

  • Page 39: Front Panel Board Power Distribution

    Kontron CG2100 Carrier Grade Server Technical Product Specification 4.13 Front Panel Board Power Distribution The power distribution for the front panel board is shown in Figure 30. Figure 30. FP Board Power Distribution 4.14 Front Panel Board Connector Specifications The following sections provide the pin definitions for the FP board connectors.
  • Page 40 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 8 Fan Connector Pin-Out Signal Name Description P12V Power Supply 12V Power Supply Ground FAN_PRSNT1_N Present Signal FAN_FAULT_LED1 Fan Fault Signal FAN_TACH1_IN Fan Tach Signal FAN_CONN_PWM1 Fan PWM Signal from FAN_PWM1 of bridge board...

  • Page 41: Front Panel Board Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification 4.14.3 Front Panel Board Connector Table 9 Front Panel Board Connector Pin-Out Signal Name Description P5VSTBY Power Supply 5V standby P5VSTBY Power Supply 5V standby FP_PWR_LED1_N Power LED 1 Signal FP_PWR_LED2_N Power LED 2 Signal...
  • Page 42 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 10 Bridge Board Connector Pin-Out Description Signal Name No Connect NC_FP_CONN_A60 No Connect NC_FP_CONN_A59 Pull down to ground with 1K ohm resistor. FP_PRESENT_N Ground No Connect NC_FP_CONN_A56 No Connect NC_FP_CONN_A55 Ground...
  • Page 43 Kontron CG2100 Carrier Grade Server Technical Product Specification Description Signal Name Connect to front panel connector ID LED FP_ID_LED_R1_N No Connect FM_SIO_TEMP_SENSOR Connect to fan connector Molex 87831-3628 FAN_FAULT_LED3 Connect to fan connector Molex 87831-3628 FAN_FAULT_LED2 Connect to fan connector Molex 87831-3628...

  • Page 44: Combo Rj45/Usb Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification Description Signal Name Connect to front panel connector LED_STATUS_GREEN_BUF_R1 No Connect LED_NIC2_LINK_N Connect to ORing diode LED_NIC2_ACT_N Connect to front panel connector LED_STATUS_AMBER_R1 Ground SMBus 3.3V data signal. Connect to FRU EEPROM SMB_SEN_3V3SB_DAT SMBus 3.3V clock signal.

  • Page 45: Internal Usb Ssd Connector

    No connect No connect ACT_LED_N Tie to green LED for USB activity indication 4.14.7 USB SD Flash Module Connector Table 14. CG2100 Front Panel Board SD Flash Module Connector Signal Name Description Power Supply Ground No connect USB1_ESB_DP USB signal...

  • Page 46: Led/Switch Board

    Kontron CG2100 Carrier Grade Server Technical Product Specification LED/Switch Board This chapter provides an overview of the Kontron Carrier Grade Server CG2100 LED/switch board, including information about the board hardware, connectors, power subsystem, optional add-ins, and regulatory requirements. This chapter is organized into the following sections: Section 5.1...

  • Page 47: Front Panel Status Leds

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 15. Control Button Functions Function Switch/Button Feature Toggles the system power on/off, also functions as a sleep button if enabled by an ACPI-compliant Power / Sleep button operating system. A status LED is embedded in this...

  • Page 48: Led/Switch Board Connector Specification

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 17. System Status LED Description Color State Criticality Description Not ready AC (or DC if DC power supplies used) power is off. Green System booted and ready Green Blinking Degraded System degraded...
  • Page 49 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 18 LED/Switch Board Connector Pin-Out Definition Definition P5VSTBY TELCO_CRIT_LED_Y_N FP_NIC_LED_N P5VSTBY FP_PWR_BTN_N FP_HDD_LED_G_N FP_PWR_LED1_N FP_RST_BTN_N TELCO_PWR_LED_N FP_HDD_LED_A_N FP_PWR_LED2_N FP_ID_BTN_N TELCO_MIN_LED_N FP_BB_LED_A_N FP_ID_LED_W_N FP_NMI_BTN_N TELCO_MAJ_LED_R_N FP_PS_LED_A_N FP_ID_LED_B_N TELCO_MAJ_LED_Y_N FP_FAN_LED_A_N FP_STAT_LED_G_N TELCO_CRIT_LED_R_N FP_STAT_LED_A_N...

  • Page 50: Sas/Sata Backplane Board

    Section 6.5 SAS/SATA Backplane Card Edge Finger Connector Introduction The CG2100 server contains a single SAS/SATA backplane board that provides support for six 2.5” SAS or SATA hard disk drives (HDDs). The backplane connects with either a SAS/SATA control module or a SAS/SATA RAID module via a 2x49-pin card edge connector to support six SAS or SATA drives.

  • Page 51: Sas/Sata Backplane Board Features

    Kontron CG2100 Carrier Grade Server Technical Product Specification SAS/SATA Backplane Board Features The backplane board contains the following features: SAS/SATA connectors for six hot-swappable disk drives • Enclosure management via an embedded controller • Serial EEPROM for hot swap controller firmware for the embedded controller •...

  • Page 52: Hard Disk Drive Activity And Fault Leds

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 34: Hard Disk Drive Bay Numbering Hard Disk Drive Activity and Fault LEDs The backplane board supports an activity/fault LED for each of the hard drive connections. The LED is green for activity or amber for a drive fault. The green activity setting is driven by the SAS/SATA directly.

  • Page 53: Sas/Sata Backplane Card Edge Finger Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification The pin definitions and power rating of the P5V, P12V, P5V_STBY, P3V3 and GND rails coming from the Power Distribution Board (PDB) through a 2x4-pin power connector are shown in Table 21.
  • Page 54 Kontron CG2100 Carrier Grade Server Technical Product Specification Pin # Definition Pin # Definition SGPIO_CLOCK P12V SAS0_RX_P SAS0_RX_N SAS1_TX_P SAS1_TX_N SAS1_RX_P SAS1_RX_N SAS2_TX_P SAS2_TX_N SAS2_RX_P SAS2_RX_N SAS3_TX_P SAS3_TX_N SAS3_RX_P SAS3_RX_N RSVD_B46 RSVD_A47 RSVD_B47 RSVD_A48 RSVD_B48 www.kontron.com...

  • Page 55: Sas/Sata Control Module

    Defines the pin-out of the card edge finger connection Introduction The CG2100 server SAS/SATA control module adds SAS/SATA support for the server. The module interface to the baseboard is through a PCI Express bus. The control module provides integrated software RAID 0/1/10 capability. Figure 35 shows the placement of the major components and connectors on the SAS/SATA control module.

  • Page 56: Sas/Sata Control Module Features

    Kontron CG2100 Carrier Grade Server Technical Product Specification SAS/SATA Control Module Features The SAS/SATA control module provides the following features: Differential SAS/SATA signals from an LSI Logic LSISAS1068E* SAS/SATA controller (Figure • 35, “B”) to the server HDD backplane through an edge finger connector;...

  • Page 57: Sas/Sata Control Module Flex Cable Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification A serial, point-to-point enterprise-level storage interface • Simplified cabling among devices • SAS/SATA Control Module Flex Cable Connector The SAS/SATA control module has a flex cable connector with PCI Express x4 signals through the connector to the LSISAS1068E controller.
  • Page 58 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 24. SAS/SATA Control Module 2x49 Card Edge Finger Pin-Out Pin# Pin Definition Pin# Pin Definition SGPIO_CLOCK P12V SGPIO_LOAD P12V P3V3 SGPIO_DATAOUT0 SGPIO_DATAOUT1 NC_RSVD_A6 LED_HDD_FLT_L RSVD_B7 LED_HDD_ACT_L RSVD_B8 SMB_SAS_3V3_SCL SMB_SAS_3V3_SDA SMB_IPMB_5VSB_CLK RST_PS_PWRGD...

  • Page 59: Sas/Sata Raid Module

    SAS/SATA RAID Module Intelligent Battery Backup Unit Connector (J4L1) Introduction This section provides an overview of the features of the CG2100 server SAS/SATA RAID module that shows how the SAS RAID module interconnects with the other components of the CG2100 server.

  • Page 60: Sas/Sata Hardware Raid Module Functional Blocks

    Kontron CG2100 Carrier Grade Server Technical Product Specification RAID module provides a cost-effective and performance-optimized configurable hardware RAID controller for the CG2100 server. The block diagram in Figure 38 shows the major hardware components of the SAS RAID module on the CG2100 server.

  • Page 61: Nvram

    Kontron CG2100 Carrier Grade Server Technical Product Specification 8.3.4 NVRAM The NVRAM is 256 Kbits of accessible static RAM. The NVRAM is used to store hardware RAID controller configuration information and disk drive RAID configuration information. 8.3.5 DDRII Bus The SAS/SATA RAID module DDRII bus runs at speeds up to 667 MHz and supports 256 Mbytes of registered DDRII memory.

  • Page 62: I-Button

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 25: GPIO Descriptions LSI GPIO # GPIO Description GPIO 0 RSVD GPIO 1 RSVD GPIO 2 FW Reads to determine if BIOS should be disabled by FW GPIO 3 Output on HW RAID Error -- Enables Speaker...

  • Page 63: Battery Backup Power Control

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 39 SMBus Block Diagram 8.3.10 Battery Backup Power Control The Battery backup voltage supports the DDRII SDRAM memory to maintain data integrity during a power failure. The Battery backup voltage (VBAT_RAID) power rail can be supplied from several sources and the battery backup power controller determines the appropriate source to activate.

  • Page 64: 33 Mhz System Reference Clock

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 40 Clock Generation/Distribution 8.5.1 33 MHz System Reference Clock The 33 MHz clock is generated by an on-board oscillator and is used by the hardware RAID controller. 8.5.2 150 MHz SAS Clock The 150 MHz clock is generated by an on-board oscillator and is used by the hardware RAID controller.

  • Page 65: Sas/Sata Raid Module Status Leds

    Kontron CG2100 Carrier Grade Server Technical Product Specification SAS/SATA RAID Module Status LEDs Table 26 shows the system status LEDs that can be used to determine system operation. Table 26: Clock Generation/Distribution Status LED Functions Color Function Write Pending (DS2D1)

  • Page 66: Sas/Sata Raid Module Edge Connector (J2D1)

    Kontron CG2100 Carrier Grade Server Technical Product Specification SAS/SATA RAID Module Edge Connector (J2D1) This connector provides the connection for the six SAS/SATA channels from the hardware RAID controller to the SAS/SATA backplane. It also provides the SMBus connection to and from the backplane and status signals.

  • Page 67: Sas/Sata Raid Module Ibbu Connector (J4L1)

    Kontron CG2100 Carrier Grade Server Technical Product Specification Pin # Definition Pin # Definition RSVD_A48 RSVD_B48 8.10 SAS/SATA RAID Module IBBU Connector (J4L1) The intelligent battery backup unit (IBBU) connector carries signals between the SAS/SATA RAID module and the IBBU. The signals carried are power, I C, and control signals.

  • Page 68: Telco Alarms Module (Tam)

    Kontron CG2100 Carrier Grade Server Technical Product Specification Telco Alarms Module (TAM) This chapter describes the design and external interface of the Kontron Carrier Grade Server CG2100 Telco Alarms Module assembly. The chapter is organized into the following sections: Section 9.1 Introduction Section 9.2...

  • Page 69: Telco Alarms Module Features

    Kontron CG2100 Carrier Grade Server Technical Product Specification Item Description System Interface Connector External Telco Alarms Connector Telco Alarm Relays Telco Alarms Module Features The Telco Alarms Module provides the logic and relays for controlling the telco alarm LEDs displayed on the front panel board.

  • Page 70: Telco Alarms Fault Leds

    Kontron CG2100 Carrier Grade Server Technical Product Specification 9.2.1 Telco Alarms Fault LEDs Switch Function Critical The critical alarm LED can be either amber (default) or red (set with an FRUSDR update). This LED is illuminated by the BMC private I...

  • Page 71: Telco Alarms System Interface Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 30 Telco Alarms External Interface Connector Pin-Out Signal Name Description MINOR_RST_POS Minor reset positive MINOR_RST_NEG Minor reset negative MAJOR_RST_POS Major reset positive MAJOR_RST_NEG Major reset negative CRITICAL_NO Critical alarm normally open...

  • Page 72: Telco Alarms Module Mechanical Drawing

    Kontron CG2100 Carrier Grade Server Technical Product Specification Telco Alarms Module Mechanical Drawing Figure 43. Telco Alarms Module Mechanical Drawing www.kontron.com...

  • Page 73: Usb Sd Flash Module

    Section 10.3 USB SD Flash Module Connector Specification 10.1 Introduction The CG2100 server USB SD flash module board provides connectors and supporting logic for two SD flash memory card slots. Figure 44 shows the SD flash module components. Figure 44. SD Flash Module Layout (Primary Side)

  • Page 74: Usb Sd Flash Module Features

    Kontron CG2100 Carrier Grade Server Technical Product Specification 10.2 USB SD Flash Module Features Figure 45 shows the SD flash module block diagram. Figure 45: SD Flash Module Block Diagram 10.3 USB SD Flash Module Connector Specifications This section provides the pin definitions for the SD flash module connectors.

  • Page 75: Sd Card Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification Signal Name Description Ground Pin pulled for connector keying USB_DP USB Differential Pair (+) Power (+5V) USB_DN USB Differential Pair (-) Ground ACT_LED_N Activity LED No Connection 10.3.2 SD Card Connector The SD card connector provides the interface to standard plug-in SD Card memory devices. Pin 1 on the SD flash connectors is the bottom pin when looking at the module as shown in Figure 46.

  • Page 76: Pci Riser Card Assembly

    Kontron CG2100 Carrier Grade Server Technical Product Specification 11. PCI Riser Card Assembly This chapter describes the design and external interface of the Kontron Carrier Grade Server CG2100 PCI riser card assembly. This chapter is organized into the following sections: Section 11.1...

  • Page 77: Riser Card Mechanical Drawings

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 47. PCI Add-In Card Options 11.3 Riser Card Mechanical Drawings Figure 48, Figure 49, and Figure 50 are mechanical drawings for both primary and secondary sides of each of the three riser card options.

  • Page 78: Figure 48: 2U Butterfly Pci Express* Riser

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 48: 2U Butterfly PCI Express* Riser Primary Side Secondary Side www.kontron.com...

  • Page 79: Figure 49: 2U Butterfly Pci-X/Pci Express Active Riser

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 49: 2U Butterfly PCI-X/PCI Express Active Riser Primary Side Secondary Side www.kontron.com...

  • Page 80: Figure 50: 2U Pci Express Passive Riser

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 50: 2U PCI Express Passive Riser Primary Side Secondary Side www.kontron.com...

  • Page 81: Dc Power Subsystem

    The CG2100 DC power supply is mechanically identical to another DC power supply used in several other systems as show in the table below. Either power supply can be installed into the CG2100 system as well as the other systems. The difference is only in the protocol of the power system management bus.

  • Page 82: Dc Power Supply To Pdb Interconnect

    Kontron CG2100 Carrier Grade Server Technical Product Specification 600W subsystem output capability in full DC input voltage range • Power Good indication LEDs • Predictive failure warning • Internal cooling fans with multi-speed capability • Remote sense of 3.3 V, 5 V, and 12 Vdc (on the PDB) outputs •...

  • Page 83: Dc Power Supply Input Connector

    Kontron CG2100 Carrier Grade Server Technical Product Specification 12.3 DC Power Supply Input Connector Figure 52 shows the power input connector on the DC-input power supply module. Figure 52. DC Power Supply Input Connector The polarity for the connector is marked on the power supply housing; in this view, “-“is on the left and “+”...

  • Page 84: Dc Power Supply Input Voltage And Current Requirements

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 36. Output Connector Pin-Out Signal Pins Position +12VRS -12V +5VSB 15VCC PWOK RS RTN +5VSB +12VLS RESERVE PS KILL PS ON# PS ALERT# Power Blades +12V +12V 12.6 DC Power Supply Input Voltage and Current Requirements The DC power supply input voltage and input current requirements are listed in Table 37.

  • Page 85: Dc Power Supply Led Indicator

    Kontron CG2100 Carrier Grade Server Technical Product Specification 12.8 DC Power Supply LED Indicator The power supply module provides a single external bi-color LED to indicate the status of the power supply. When DC is applied to the PSU and standby voltages are available, the LED blinks green.

  • Page 86: Power Distribution Board (Pdb)

    Kontron CG2100 Carrier Grade Server Technical Product Specification 13. Power Distribution Board (PDB) This chapter defines the features and functionality of the power distribution board (PDB), which is used in conjunction with a DC or AC input power supply module to complete the power subsystem.

  • Page 87: Pdb +12V Output Load Requirements

    Kontron CG2100 Carrier Grade Server Technical Product Specification Figure 56: PDB Input Connector Table 40. PDB Input Connector Pin-Out Signal Pins Position +12VRS -12V +5VSB 15VCC PWOK RS RTN +5VSB +12VLS RS RTN PS KILL PS ON# PS ALERT# Power Blades...

  • Page 88: Pdb D2D Converters Loading

    Kontron CG2100 Carrier Grade Server Technical Product Specification 13.4 PDB D2D Converters Loading Table 42 defines power and current ratings for the three D2D converters located on the PDB, each powered from +12V rail. The three converters meet both static and dynamic voltage regulation requirements for the minimum and maximum loading conditions.

  • Page 89: Pdb Output Interface Connectors

    Kontron CG2100 Carrier Grade Server Technical Product Specification PMBus™ Power System Management Protocol Specification Part II – Command Language; • Revision 1.2 System Management Bus (SMBus) Specification Version 2.0 • 13.8 PDB Output Interface Connectors 13.8.1 Baseboard Connector Card Edge The PDB has a card edge connection to the baseboard.

  • Page 90: Hdd Backplane Power Connector (Fpio)

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 44. PDB Card Edge Connector Pin-Out Pin# Definition Signal pins PWOK PSON# -12VDC SMBus Clock SMBus Data SMBAlert# Return Sense 3.3V remote sense +5VSB +5VSB 5V remote sense +5VSB Power 12V3...
  • Page 91 Kontron CG2100 Carrier Grade Server Technical Product Specification Table 46. I/O Power Connector Pin-Out Pin # Definition 12V5 +5VDC 12V5 +5VDC COMM COMM COMM COMM www.kontron.com...

  • Page 92: Ac Power Subsystem

    The CG2100 AC power supply is mechanically identical to another AC power supply used in several other systems as show in the table below. Either power supply can be installed into the CG2100 system as well as the other systems. The difference is only in the protocol of the power system management bus.

  • Page 93: Figure 58. Ac Power Supply Module Mechanical Drawing

    Kontron CG2100 Carrier Grade Server Technical Product Specification Remote sense of 3.3 V, 5 V, and 12 Vdc outputs • AC_OK circuitry for brown out protection and recovery • Brown out protection and recovery • Built-in overloading protection capability •...

  • Page 94: Ac Power Supply Input Voltage And Current Requirements

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 48. AC Output Connector Pin-Out Signal Pins Position +12VRS -12V +5VSB 15VCC PWOK RS RTN +5VSB +12VLS RESERVE PS KILL PS ON# PS ALERT# Power Blades +12V +12V 14.1 AC Power Supply Input Voltage and Current Requirements The AC power supply input voltage and current requirements are listed in Table 49.

  • Page 95: Ac Power Supply Output Current Requirements

    Kontron CG2100 Carrier Grade Server Technical Product Specification Maximum 6A @90Vrms / 3A @180Vrms Frequency Minimum 47 Hz Rated 50/60 Hz Maximum 63 Hz 14.2 AC Power Supply Output Current Requirements The power supply module provides three main outputs; +12V, -12V, and 5V standby, along with the 15VBIAS voltage.

  • Page 96: Ac Power Supply Air Flow

    Kontron CG2100 Carrier Grade Server Technical Product Specification Table 51: LED Indicator Status Conditions Power Supply Condition Bi-color LED No AC power to all power supplies No AC power to this PSU only (for 1+1 configuration) Amber Power supply critical event causing a shutdown:...

  • Page 97: Regulatory Specifications

    , and Low Voltage Directive, 73/23/EEC. 2004/108/EC 15.4 NEBS Compliance The CG2100 Carrier Grade Server system with DC input is compliant with the NEBS.Level 3 criteria and the system with AC input is compliant with NEBS Level 1 criteria from the following NEBS specifications: •...
  • Page 98 Kontron CG2100 Carrier Grade Server Technical Product Specification • ETS 753 — Acoustic Noise www.kontron.com...

  • Page 99: Appendix A: Glossary

    Kontron CG2100 Carrier Grade Server Technical Product Specification Appendix A: Glossary This appendix contains acronyms and terms used in the preceding chapters. Term Definition A, Amp Ampere A/µs Amps per microsecond Alternating current ACPI Advanced Configuration and Power Interface ANSI...
  • Page 100 Kontron CG2100 Carrier Grade Server Technical Product Specification Term Definition Fahrenheit Federal Communications Commission Flexible flat connector Flash ROM EEPROM Front panel controller Fault resilient booting Field replaceable unit Acceleration in gravity units, 1G = 980665 m/s2 Gb, Gbit Gigabit GB, Gbyte Gigabyte –...
  • Page 101 Kontron CG2100 Carrier Grade Server Technical Product Specification Term Definition Network interface card Non-maskable interrupt NWPA NetWare* Peripheral Architecture Open data-link interface Original equipment manufacturer OPROM Option ROM (expansion BIOS for a peripheral) Operating system Over-temperature protection Over-voltage protection PC-100...
  • Page 102 Kontron CG2100 Carrier Grade Server Technical Product Specification Term Definition Serial Presence Detect Server System Infrastructure Technischer Uberwachungs-Verein (A safety testing laboratory with headquarters in Germany) Underwriters Laboratories, Inc. Universal Serial Bus Under-Voltage Volt Volt-amps (volts multiplied by amps) Volts alternating current...
  • Page 103 Kontron CG2100 Carrier Grade Server Technical Product Specification www.kontron.com...
  • Page 104 Kontron CG2100 Carrier Grade Server Technical Product Specification Corporate Offices Europe, Middle East & North America Asia Pacific Africa 14118 Stowe Drive 17 Building, Block #1, Poway, CA 92064-7147 ABP. Oskar-von-Miller-Str. 1 188 Southern West 4th 85386 Eching/Munich Tel.: +1 888 294 4558...

Table of Contents
