⚫ Display
◼ 1 x DVI :Support DVI-D, max resolution up to 1920x1200@60Hz
◼ 1 x HDMI 1.4b (TYPE-A): up to 4096x2160@30Hz
◼ 1 x VGA (DB15/F): max resolution up to 1920x1200@60Hz
⚫ Expansion Interface
◼ 1 x PCI-E x16 Slot (PCIe x16, GEN4)
◼ 3 x PCI-E x4 Slot 1/ 3/ 4 (PCIe x4, GEN4)
◼ 1 x PCI-E x4 Slot2 (PCIe x4, GEN3)
◼ 1 x PCI Slot (Support CLK 66MHz)
◼ 1 * M.2 Key-E Slot (PCIE+USB2.0+ CNVi, support WIFI +Bluetooth Module, 2230)
◼
1 * M.2 Key-M Slot (PCIe x4 GEN4 NVMe/SATA SSD Auto Detect,2280)
⚫ Power Input
◼ 1 * ATX 8P CPU Power Input Connector
◼ 1 * ATX 4P CPU Power Input Connector
◼ 1* ATX 24P CPU Power Input Connector
⚫
Operating Temperature
◼ 0°C ~ 60°C
⚫ Storage Temperature
◼ -20°C ~ 75°C
⚫
Form Factor
◼
305 x 244mm
All specifications and images are subject to change without
notice.
Note
1.3

Packing list

Bulk packing
⚫
◼ 1 x Motherboard
◼ 1 x I/O bracket
Gift box
⚫
1 x Motherboard
◼
1 x I/O bracket
◼
