DIMM2
DIMM3
DIMM1
PCIE_16X_SLOT1
PCIE_4X_SLOT1
PCIE_4X_SLOT2
PCIE_4X_SLOT3
PCIE_4X_SLOT4
PCI1
PS/2_USB1(PS/2)
PS/2_USB1(USB)
DVI_VGA1(DVI)
DVI_VGA1(VGA)
COM1
HDMI1
RJ45_USB2(LAN)
RJ45_USB2(USB)
RJ45_USB1(LAN)
AUDIO1
Board and Pin Assignments
DDR4 CHB DIMM Slo3
DDR4 CHA DIMM Slot2
DDR4 CHA DIMM Slot1
PCI-E 16x Slot1 (PCIe 4X)
PCI-E 4x Slot1 (PCIe 4X)
PCI-E 4x Slot2 (PCIe 3X)
PCI-E 4x Slot3 (PCIe 4X)
PCI-E 4x Slot4 (PCIe 4X)
PCI Slot
PS/2 Connector (Keyboard & Mouse)
Dual USB3.0 TYPE-A Connector
DVI-I 24+4P/F Connector (Support DVI-D)
VGA DB15/F Connector
COM1 DB9/M Connector
HDMI TYPE-A Connector
GBE LAN RJ45 Connector2
Dual USB3.0 TYPE-A Connector2
GBE LAN RJ45 Connector1
Line-Out + MIC + Line-In 3.5mm Jack
