PCI-Express x4 Slots (PCIE_4X_SLOT1, SLOT2, SLOT3,
SLOT4)
This motherboard has four PCI-Express x4 slots
Pin
Signal
B1
+12V_PS
B2
+12V_PS
B3
+12V_PS
B4
GND
B5
SMB_CLK_RESUME
B6
SMB_DATA_RESUME
B7
GND
B8
+3.3V_PS
B9
N/C
B10
+3.3V_SB
B11
PCH_WAKE_N
B12
N/C
B13
GND
B14
PCIE1_SLOT1_TX_DP_C
B15
PCIE1_SLOT1_TX_DN_C
B16
GND
B17
PCIEX4_SLOT1_PRSNT2_N
B18
GND
B19
PCIE2_TX_DP
B20
PCIE2_TX_DN
B21
GND
B22
GND
B23
PCIE3_TX_DP
B24
PCIE3_TX_DN
B25
GND
B26
GND
B27
PCIE4_TX_DP
B28
PCIE4_TX_DN
B29
GND
B30
N/C
B31
N/C
B32
GND
PCIE_4X_SLOT2 support the PCIE 4X GEN3 signal.
Note
Board and Pin Assignments
Pin
Signal
A1
GND
A2
+12V_PS
A3
+12V_PS
A4
GND
A5
N/C
A6
N/C
A7
N/C
A8
N/C
A9
+3.3V_PS
A10
+3.3V_PS
A11
PWRGD
A12
GND
A13
CLKOUT_PCIE_P5
A14
CLKOUT_PCIE_N5
A15
GND
A16
PCIE1_SLOT1_RX_DP_C
A17
PCIE1_SLOT1_RX_DN_C
A18
GND
A19
N/C
A20
GND
A21
PCIE2_RX_DP
A22
PCIE2_RX_DN
A23
GND
A24
GND
A25
PCIE3_RX_DP
A26
PCIE3_RX_DN
A27
GND
A28
GND
A29
PCIE4_RX_DP
A30
PCIE4_RX_DN
A31
GND
A32
N/C
IMB540 User's manual
23
