IMB541 User's manual
2.3.17

ESPI Header (Debug Only) 6*2 Pin 2.00mm)

Pin Signal
1 ESPI_IO0
3 ESPI_IO1-
5 ESPI_IO2
7 ESPI_IO3
9 ESPI_CS0
11 ESPI_ALERT0_N
2.3.18

Front Panel Header (F_PANEL1 )

This is a front panel header (5x2-pin p=2.54mm).
Pin Signal
1 HD LED+
2 Power LED+
3 HD LED-
4 Power LED-
5 RESET-
6 PWR+
7 RESET+
8 PWR-
9 N/C
10
18
Pin Signal
2 VCC3.3_Dual
-
6 ESPI_CLK
8 GND
10 VCC3.3S
12 PLT_RST_N
Board and Pin Assignments
