Quantum Ultra Series • Setup Guide
2. Select the number of displays. In the spin boxes labeled Number of Displays (
for the columns and the rows of the videowall. In the example in figure 4 on the next page, the wall has five columns by three
rows ( ).
4
Figure 4. Wall Configuration Window
Configure the outputs. The settings on the menus in the output configuration panel apply to all displays in the Canvas:
3.
•
Resolution (see figure 4,
• Master Refresh Rate (
NOTE: Quantum Ultra and Ultra II 610 and 305 only: This rate not only applies to all the displays on the first
Canvas, but limits selectable refresh rates on all other Canvases that are added (see the VCS Help File to use
multiple Canvases).
• Output format (see
DVI RGB 444, or HDMI RGB 444). The default is Auto.
• HDCP Mode (
always encrypt the output (default), to never encrypt the output, or to try to encrypt the output for 1 minute, then revert to
an unencrypted state (not allowing display of HDCP encrypted sources if authentication with the sink device fails).
•
HDCP Notification (
signal contains HDCP-protected content and the outputs cannot be encrypted.
•
Display Rotation (
physically rotate: +90° (90 degrees clockwise), -90° (90 degrees counterclockwise) or 0° (no
rotation). The example at right shows a videowall that has four rotated displays.
NOTE:
The OUT4HDMI cards support output rotation only on the even numbered channels
and disables the odd numbered channels. The OUT4HDMI 4K PLUS and OUT4FOX3
cards support output rotation on all channels.
) — From this drop-down list, select the output resolution for the displays.
5
) — From this drop-down list, select the refresh rate for the displays.
6
figure 4,
on the previous page) — From this drop-down list, select the output format (AUTO,
7
) — From this drop-down list, select how to manage HDCP encryption on the outputs. You can select to
8
) — From this drop-down list, select to enable or disable a green screen notification when the input
9
) — In this panel, select the radio button for the angle at which the displays
¢
