Basic SIS Commands

The Quantum Ultra Series can be controlled with SIS commands via a USB, RS-232, or LAN connection. The following table lists
some basic commands. For a full list of SIS commands and variables see the Quantum Ultra Series User Guide, available at
www.extron.com.
Command
Input Selection
Select input
View current input
Window Presets
Recall window preset
Recall preset with audio
Window Border Style (These commands apply to Quantum Ultra and Quantum Ultra II only.)
Set window border style
View window border style
Audio Selection
Select audio source
IP Configuration (These commands apply only to the LAN A port. A Commit and Reboot command is required for changes to persist.)
Set DHCP on and off
View DHCP setting
Set IP address
View IP address
Rebooting the System
Commit and reboot
KEY: X!
= Input (assigned by VCS): 0001 – 9999. Response is four digits with leading zeros.
0001 – 0999 = Physical video connections on all Quantum chassis in the system.
1000 – 9999 = Sources defined in the system and not connected to an input card (Picture, RSS, VNC, Text, or Clock).
X# = Canvas: 01 – 10. Response is two digits with a leading zero.
X%
= Window: 001 – 999. Response is three digits with leading zeros.
X1)
= On or off: 0 = off (disabled), 1 = on (enabled).
X2%
= Window preset: 001 – 128. Response is three digits with leading zeros.
X7%
= Window border style preset: 000 – 127. 000 = no border. Response is three digits with leading zeros.
X11$ = IP address in the format nnn
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Safety and Regulatory Compliance Guide
12
ASCII Command
(Host to Processor)
X# X% X!
* * !
X# X%
* !
X# X2%
1* * .
3* X# * X2% .
E X# X% X7%
WNDW }
B * *
X# * X%
E
B WNDW }
X#*X!$
E X1)
DH }
E
DH }
E X11$
CI }
E
CI }
E 1BOOT }
. . .
nnn. Default is 192.168.254.254.
nnn nnn
on the Extron website.
