Quantum Ultra Series • Setup Guide
Configuring the Videowall Using VCS
This section describes how to set up the videowall (create a project) using the VCS program to configure and control the
Quantum Ultra Series from the computer. For detailed information, see the VCS Help File, accessible from within VCS.
Starting VCS
1. Download VCS from
instructions).
2. Open the software program either by double-clicking the VCS icon (shown at right) that is placed on your
desktop during installation, or by clicking Start > Extron Electronics > Videowall Configuration Software.
The Extron VCS program opens with the Start screen, Connect tab.
3. Click the New tab to open the Create New Project tab (see figure 2,
Figure 2. VCS Start Screen, Create New Project Tab
4.
Select the Quantum Ultra / Quantum Ultra II radio button (
Ultra Series devices on the network. The New Project screen is displayed. The Select Device(s) to Add panel (see figure 3,
) displays all detected devices of the type selected on the Create New Project screen.
1
NOTE: A gateway IP address is required on the PC running VCS for the Quantum Ultra Series device to be detected.
Figure 3. New Project Screen
www.extron.com (see the Quantum Ultra Series User Guide, also available at www.extron.com, for
).
1
) and click the Create button (
2
Product Category
). VCS searches for Quantum
3
