3.3.1.4 Flash in eMMC
We use UUU tool to flash the image in eMMC for SCM188 with SCB184 platform, following
items are required:
⚫ Micro USB Cable.
⚫ Windows or Linux OS PC (recommend is Windows).
⚫ UUU tool (https://github.com/NXPmicro/mfgtools/releases)
⚫ Set the switch on SCM188 SOM to 1001 as below figure.
3.3.1.5 Flash Image by PC
To flash image via Windows/Linux PC, please follow below steps.
The link for the verified UUU tool 1.4.243 follows:
https://github.com/NXPmicro/mfgtools/releases/tag/uuu_1.4.243
→ Linux
→ Windows
⚫
Connect SCM188 with SCB184 board and PC via Micro USB cable.
⚫ Open terminal from PC and change directory to image path.
⚫ Execute below command to flash image:
For Linux PC:
For Windows PC:
⚫ Terminal will show
⚫ Remove Micro USB cable and follow ch.3.4 for boot steps.
p.s. The image flash package is maintained by Axiomtek, please contact us for more details.
SCM188 BSP User Guide
SCM188 NXP i.MX 8M Plus ARM-based SMARC Module
$ sudo ./uuu uuu_all.auto
$ uuu.exe uuu_all.auto
Done after flash successful.
<user disk path>
Set switch as 1001,
serial download mode
OS Flash Port
<user disk path>
