AXIOMTEK SCM188 User Manual page 30

SCM188 NXP i.MX 8M Plus ARM-based SMARC Module
Example:
sh-5.1# ethtool -s eth0 speed 100 duplex half
sh-5.1# ethtool -s eth0 speed 10 duplex full
⚫ Execute the below command to check the current Ethernet settings.
sh-5.1# ethtool eth0
⚫ Execute the below command to set the desired speed/duplex in the ethernet.
sh-5.1# ethtool -s eth1 speed [SPEED] duplex [DUPLEX]
Example:
sh-5.1# ethtool -s eth1 speed 100 duplex half
sh-5.1# ethtool -s eth1 speed 10 duplex full
⚫
Execute the below command to check the current Ethernet settings.
sh-5.1# ethtool eth1
Note: The Max. Speed 1000Mbps is supported if only if the SCM188 with SCB184 board is
connected in the 1000Mbps network.
26 SCM188 BSP User Guide
