⚫ COM
◼ Dual UART with TX/RX/RTS/CTS
◼ Single UART TX/RX (for debug console)
⚫ I2C
◼ Triple I2C interface
⚫ QSPI
◼ Single QSPI
⚫ SPI
◼ Single SPI
⚫ CANbus
◼ Dual CANbus
⚫ GPIO
◼ 14 x GPIO
⚫ OS Flash
◼ Single OS Flash for flash image
⚫ Audio
◼ Dual I2S interfaces
⚫ Camera Input
◼ Single MIPI-CSI 4-lane
◼ Single MIPI-CSI 2-lane
⚫
Security
◼ TPM2.0 (option, none in default)
⚫ PCIe
◼ Single PCIe Gen3 x1
⚫
Power Requirement
+5V ± 5%
◼
⚫ Form Factor
82mm x 50mm (approx. 3.23" x 1.97")
◼
Thickness as 1.2mm ± 0.1mm
◼
◼ SMARC specifications V2.1 compliant
⚫ Environments
◼ Operating temperature: -40ºC to +85ºC (-40ºF to +185ºF)
◼
Operating Humidity: 10% to 95%, non-condensing
◼ Storage temperature: -40°C to +85°C (-40°F to +185°F)
◼ Storage Humidity: 10% to 95%, non-condensing
Note: All specifications and images are subject to change without notice.
