Example:
Assume SD card attached at /dev/sdf, image name is imx-image-full-scm188.wic.bz2
$ bzcat imx-image-full-scm188.wic.bz2 | sudo dd of=/dev/sdf bs=1M conv=fsync
0+1290634 records in
0+1290634 records out
6493345792 bytes (6.5 GB, 6.0 GiB) copied, 153.449 s, 42.3 MB/s
3.3.1.3 Flash Image by Windows PC
To flash image by Windows, please download the "Rufus" by following link.
https://rufus.ie/downloads/
The link for the verified Rufus v3.12 follows:
https://github.com/pbatard/rufus/releases/download/v3.12/rufus-3.12p.exe
The step to flash BSP image to SD card by Windows:
⚫ Insert SD card using SD card reader to the PC.
⚫ Execute flash utility, use Rufus for example
⚫ Step1: check SD card has been recognized.
⚫ Step2: click select button to select image:
< SCM188 with SCB184_image_name>.wic.bz2
⚫ Step3: click start button, it will format SD card then start flashing image.
18
Step 3
Step 1
Step 2
