Zippity ZURICH ZP19079 Manual

x4
A
RECOMMENDED TOOLS
Drill / Phillips Bit Hammer
1
Assemble on soft surface
to prevent scratching
Approximate assembly + Installation time
2
p t o w
r a i l u
l d u r i
P u s h
i n r a i
s l a t s
3
Align rail just
beneath pickets
4
Some force may be
required to drive screws.
D
E
F
x20 x3
B C
(Not Included)
Scrap Wood Block Level
60 MIN
h o l d
a l l t o
l y
s e m b
n g a s
Place pickets inside
bottom rail one by one

D
x8
x3
x3
x4
Use a scrap wood block
to protect stakes. Check
for level every few taps.
Leave 1.5" of the stake
exposed if you would
like to raise the panel as
shown in the next step.
(Optional)
Use part (F) to raise panels
off the ground as shown.
(Optional For Slope)
Step panels by installing the
lower panel beneath part (F).
5
6
1.5"
7
Do not overtighten
screw
8
