ASSEMBLY INSTRUCTIONS
MANCHESTER
VINYL PICKET GATE
WITH POSTS
Approximate assembly time
Want to see a video on how to
WWW.ZIPPITY-OUTDOOR.COM
WWW.ZIPPITY-OUTDOOR.COM
(42" W X 42"H)
60 MIN
assemble this product?
Scan the QR code
ASSEMBLY
INSTRUCTIONS
ZP19019
ZP19019
VER. 011521
1
Advertisement
Related Manuals for Zippity ZP19019
Summary of Contents for Zippity ZP19019
- Page 1 ZP19019 ASSEMBLY INSTRUCTIONS MANCHESTER ASSEMBLY INSTRUCTIONS VINYL PICKET GATE WITH POSTS ZP19019 (42” W X 42”H) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.ZIPPITY-OUTDOOR.COM VER. 011521 WWW.ZIPPITY-OUTDOOR.COM...
- Page 2 ZP19019 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 ZP19019 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-Assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
- Page 4 ZP19019 ASSEMBLY INSTRUCTIONS 6 ft 2 3/4 in 45 3/8 in 42 in 36 in 31 1/2 in 8 in 42 1/2 in Gate Opening Ground 2 in 24 in 49 1/2 in Outside Posts WWW.ZIPPITY-OUTDOOR.COM...
- Page 5 ZP19019 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: ⅝” White Self- Drilling Stainless L Bracket (4) Post Cap (2) Post (2) Steel Screw (27) 2" x 3½" x 52" ⅞" x 1½" x 40½" 2” Self-Drilling Stainless Steel Screw (4) Picket (8) ⅝”...
- Page 6 ZP19019 ASSEMBLY INSTRUCTIONS ASSEMBLE GATE FRAME STEP 2: STEP 2.1 STEP 2.2 Align the pre-drilled holes in the Top and Bottom Rails with the pre-drilled holes in the Vertical Stiles. Fasten Slide the Top and Bottom Rails to the Vertical Stiles with (2) ⅝” White Self-Drilling...
- Page 7 ZP19019 ASSEMBLY INSTRUCTIONS ASSEMBLE AND ATTACH GATE BRACES STEP 3: STEP 3.1 Fit the Gate Braces together as shown. The two Gate Braces should nest together tightly to create an “X” pattern. Flush STEP 3.2 On the back of the gate frame (the side with no screws), align the pre-drilled holes on the Gate Braces with the pre-drilled holes on the Top and Bottom Rails.
- Page 8 ZP19019 ASSEMBLY INSTRUCTIONS FINISH GATE ASSEMBLY STEP 4: STEP 4.1 STEP 4.2 Insert Pickets down through the Top STEP 4.3 STEP 4.4 Align the pre-drilled Fasten the Gate Hinges to one side of the hole on the Latch gate with (8) ⅝” Black Self-Drilling Stainless...
- Page 9 ZP19019 ASSEMBLY INSTRUCTIONS ASSEMBLE GATE POSTS STEP 5: STEP 5.1 Insert the Post Extension into the bottom of the Post as shown. Align the pre-drilled holes on the Post with the pre-drilled holes in the Post Extension, and fasten them together with (4) ⅝”...
- Page 10 ZP19019 ASSEMBLY INSTRUCTIONS INSTALL GATE STEP 7: STEP 7.1 STEP 7.2 Open the gate, and fasten the Gate Hinges to the inside Fasten the Gate Hinges of the Posts using (8) ⅝” to the Posts with (8) ⅝” Black Self-Drilling Stainless Black Self-Drilling Stain- Steel Screws as shown.
- Page 11 ZP19019 ASSEMBLY INSTRUCTIONS INSTALL POST CAPS STEP 8: STEP 8.1 Push the two Post Caps onto the Posts as shown. WWW.ZIPPITY-OUTDOOR.COM...
