- Page 1 NEWBERRY ASSEMBLY INSTRUCTIONS WOOD FENCE KIT ZP19075 (48" W X 32" H) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.ZIPPITY-OUTDOOR.COM VER. 082223...
- Page 2 ( Continental US and Canada only support@zippity-outdoor.com 704-892-5222 877-234-6196 Customer service agents are available to take calls weekdays from 9am- 5pm EST. If you call outside of business hours, please leave a voicemail.
- Page 3 21/3" 32" 121/4" 3/4" 48"...
-
Page 4: Recommended Tools
LAY OUT MATERIALS LARGE PARTS (Rail with drainage holes) Bottom Rail (2) Top Rail (2) 1" x 3" x 402/3" 1" x 3" x 402/3" Ground Stake (3) 3/4" Diameter x 443/4" End Post (4) Slat (14) 1" x 3" x 32" 1/2"... -
Page 5: Assemble Unit
ASSEMBLE UNIT (Rail with drainage holes) Assemble on box or other smooth surface to prevent scratching Push post up to wall to hold slats in post during assembly... - Page 7 ...
- Page 8 Repeat steps 1-6 to create second panel Drainage holes should face down Drilled side of stake faces down...
- Page 9 Use scrap wood block to protect stake. Check for level every few taps. Do not install stake caps 1.5" before hammering into the ground Leave ~1.5" from the top of the stake to the top of the panel Pass stake through rings on two panels to extend the fence run 1.5"...
- Page 10 (Recommended) Lift the panels and install stake peg to raise the panels off the ground Optional - Sloped Surface (Optional) Step panels by installing the lower panel beneath the stake peg. For a surface that drops more than 3" across the length of a panel please call our customer service team at (704-892-5222...
- Page 12 6935 Reames Rd. Ste. K. Charlotte, NC 28216 support@zippity-outdoor.com 704-892-5222 877-234-6196 WWW.ZIPPITY-OUTDOOR.COM...
