ASSEMBLY INSTRUCTIONS
WASHINGTON
VINYL PICKET FENCE
Approximate assembly time for two
Want to see a video on how to
WWW.ZIPPITY-OUTDOOR.COM
WWW.ZIPPITY-OUTDOOR.COM
KIT 2-PACK
(30"H X 42"W)
45 MIN
fence panels
assemble this product?
Scan the QR code
ASSEMBLY
INSTRUCTIONS
ZP19048
ZP19048
VER. 020521
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Zippity WASHINGTON
Summary of Contents for Zippity WASHINGTON
- Page 1 ZP19048 ASSEMBLY INSTRUCTIONS WASHINGTON ASSEMBLY INSTRUCTIONS VINYL PICKET FENCE KIT 2-PACK ZP19048 (30”H X 42”W) 45 MIN Approximate assembly time for two fence panels Want to see a video on how to assemble this product? Scan the QR code WWW.ZIPPITY-OUTDOOR.COM VER.
- Page 2 If you experience any further trouble with your product, please contact our customer service department. parts.nychbrands.com support@zippity-outdoor.com 704-892-5222 877-234-6196 Customer service agents are available to take calls weekdays from 9am- 5pm EST. If you call outside of business hours, please leave a voicemail.
- Page 3 ZP19048 ASSEMBLY INSTRUCTIONS 2 7/8 in 37 5/8 in WWW.ZIPPITY-OUTDOOR.COM...
- Page 4 #1(4) - ¼” x 1¼” x 25½” #2(4) - ¼” x 1¼” x 23¼” #3(4) - ¼” x 1¼” x 21¾” Post (4) 1” Self-Drilling Stainless #4(4) - ¼” x 1¼” x 21” ⅞” x 1½” x 41½” Steel Screw (8) (Bag B) WWW.ZIPPITY-OUTDOOR.COM...
- Page 5 (8) ¾” Self-Drilling Stainless Steel Screws (H). Align holes Note: Make sure picket holes on the bottom rail are facing up. Orient the bottoms of the posts as shown. WWW.ZIPPITY-OUTDOOR.COM...
- Page 6 The tabs on the bottom of the pickets go into the bottom rail to lock the picket into place. ASSEMBLE THE SECOND FENCE PANEL STEP 4: STEP 4.1 Repeat steps 2 and 3 to assemble the second fence panel. WWW.ZIPPITY-OUTDOOR.COM...
- Page 7 Add water to loosened soil. 3. Use a block of wood to protect the top of the post and gently hammer the post into the ground. Push down on the top of posts with both hands. WWW.ZIPPITY-OUTDOOR.COM...
- Page 8 Use a 1¾” diameter auger bit (commonly used for planting tulips) as illustrated ($15-$20 on Amazon.com). Drill a hole about 12” to 16” deep at the desired location, and fill the holes with water as illustrated. Push the fence posts into the holes. WWW.ZIPPITY-OUTDOOR.COM...
- Page 9 Fasten the fence panels together using (2) Joiner Clips and (4) 1” Self-Drilling Stainless Steel Screws as illustrated. Extra joiner clips and screws are included if you intend to attach the unit to other fence panels. 45° 90° installation installation WWW.ZIPPITY-OUTDOOR.COM...
- Page 10 ZP19048 ASSEMBLY INSTRUCTIONS INSTALL POST CAPS STEP 7: STEP 7.1 Push the Post Caps over the top of the posts to complete the assembly. The post caps will lock into place when pushed over the posts. WWW.ZIPPITY-OUTDOOR.COM...
- Page 11 ZP19048 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 support@zippity-outdoor.com 704-892-5222 877-234-6196 WWW.ZIPPITY-OUTDOOR.COM WWW.ZIPPITY-OUTDOOR.COM...
