DPM-400 Loop-Powered Feet & Inches Meter
Instruction Manual
•
1/8 DIN Loop-Powered Feet & Inches Meter with NEMA 4X, IP65 Front
•
4-20 mA Input Displayed with ±0.02% FS Accuracy
•
1.5 Volt Drop (4.5 Volt Drop with Backlight)
•
0.7" (17.8 mm) 5 Digits 7-Segment, FT-IN & Fractions, Top Display
•
0.4" (10.2 mm) 8 Alphanumeric Characters Bottom Display
•
Displays Level in Feet & Inches up to 999 Feet, 11 & 15/16 Inches
•
Display Input in Two Different Scales Simultaneously - Great for Level
•
20-Segment Bargraph with Numeric Percent Indication
•
Shallow Depth Case Extends Only 3.6" (91 mm) Behind Panel
•
(2) Open Collector Outputs Standard; Assigned to Pulse, Alarm, Timer, or Stopwatch
•
(2) Optional Loop-Powered Solid State Relays; Assigned to Alarm, Control, Timer, or Stopwatch
•
Stopwatch & Timer Functions to Drive Relays & Open Collectors
•
Optional Isolated 4-20 mA Analog Output
•
Relay Pump Alternation Based on Level and Runtime
•
Display Relay Runtime & Cycle Count via Relay Info Menu
•
Free PC-Based MeterView XL USB Programming Software
•
®
HART
Protocol Transparent
•
Loop-Powered Backlight with Red Backlight for Alarm Conditions
•
Operating Temperature Range: -40 to 167°F (-40 to 75°C)
•
Conformal Coated PCBs for Dust & Humidity Protection
•
Password Protection
•
Plastic NEMA 4X Enclosures for up to 10 Meters
•
Stainless Steel Sun Hood Available
•
3-Year Warranty
BINMASTER
Division of Garner Industries LLC
7201 North 98th Street, Lincoln, NE 68507 USA
•
Tel (800) 278-4241
Fax: (402) 434-9133
www.binmaster.com
