Wenger Corner Pocket Replacement Instructions

For stagetek staging system

Download this manual

StageTek Outdoor Staging System Owner's Manual 284A099.

Make sure anyone assembling, installing or

using this product has read and understands

these instructions.

Visit the StageTek Staging System web page at wengercorp.com for more information.

Note: Please read and understand these instructions before proceeding.

Note: If you need additional information, contact Wenger Corporation using the information below.

©Wenger Corporation 2024

Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448

Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com

Basic Instructions only!

For more detailed product information, refer to the

StageTek Staging System Owner's Manual 280A099 or

CAUTION

Replacement Instructions

for StageTek

Failure to comply with Warnings and Cautions in

this document or on the equipment can result in

damage to property or injury.

Printed in USA 2024-06

Corner Pocket

Staging System

CAUTION

Part #280A371-01

Need help?

Do you have a question about the Corner Pocket and is the answer not in the manual?

Page 1 Visit the StageTek Staging System web page at wengercorp.com for more information. Note: Please read and understand these instructions before proceeding. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2024 Printed in USA 2024-06 Part #280A371-01 Wenger Corporation, 555 Park Drive, P.O.
Page 2 Two people are recommended to lift the platform decks. 2. If there is a leg attached to the corner pocket being replaced, remove the leg before proceeding. 3. Remove the corner pocket casting. a. Remove and discard the four 3/8-16 x 1-1/4 Torx screws ®...
Page 3 Attach New Corner Pocket 1. Attach the new corner pocket casting. a. Position the new casting onto the deck underside and align the edges with both frame extrusions. Corner Pocket Casting b. Attach the casting to the frame extrusions using four new 3/8-16 x 1-1/4 torx screws.
Page 4 This page is intentionally blank.
