Locker with
Metal Base
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fastener Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fasteners - Not Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Layout Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wood Locker with Metal Base Components . . . . . . . . . . . . . . . . . 6
Wood Locker without Metal Base Components . . . . . . . . . . . . . . 7
Visit the GearBoss Customizable Wood Lockers web page at gearboss.com for more information.
Note: Please read and understand these instructions before starting the assembly or installation.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2021
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Installation and Owner's Instructions
Customizable Wood Lockers
Electrical Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation with Metal Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation without Metal Base . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connect Lockers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connect Locker Sides Together . . . . . . . . . . . . . . . . . . . . . . 16
Secure to Structure (Wall Mount Only) . . . . . . . . . . . . . . . . . 19
Secure to Structure (Island Mount Only). . . . . . . . . . . . . . . . 20
Helmet & Shoulder Pad Accessory Installation . . . . . . . . . . . . . . . 26
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Printed in USA 2021-11
Locker without
Metal Base
Part #241D497-11
