Wenger Conductor’s Chair Adjustment Instructions

Wenger Conductor’s Chair Adjustment Instructions

Height adjustment instructions

Advertisement

7/16" Open-end wrench and 1/8" Allen wrench required.
1. Lay the chair on its side and separate the seat from the base.
Set all loose components aside for reassembly.
Note: Please read and understand these instructions before adjusting.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2019
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com

Height Adjustment Instructions only!

For more detailed product information, refer to the
Conductor's Chair Assembly Instructions 157C002.
Seat
Printed in USA 2019-05

Height Adjustment Instructions

Conductor's Chair
Longer capscrews
at the back
Base
Part #157A160-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Conductor’s Chair and is the answer not in the manual?

Questions and answers

Summary of Contents for Wenger Conductor’s Chair

  • Page 1 Longer capscrews at the back Base Note: Please read and understand these instructions before adjusting. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2019 Printed in USA 2019-05 Part #157A160-01 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448...
  • Page 2 2. Tip the base upright and locate the adjustment screw. 3. Use a 1/8” allen wrench to turn the adjustment screw. Turn the screw clockwise to allow less adjustment lever movement. Turn the screw counter-clockwise to allow more adjustment lever movement. 4.
