Specifications

Input Current
Input Voltage
Operating
Temperature
Storage
Temperature
Hazardous Locations Information
Trademark
Model
Rating
ATEX Information
Address of
Manufacturer
Hazardous
Locations
Certifications
Special Conditions of Use
1. The equipment shall only be used in an area with a pollution degree
2 or lower as defined in EN IEC 60664-1.
2. The equipment shall be installed in an enclosure that provides a
minimum ingress protection of IP54 in accordance with EN IEC
60079-0.
3. For surge protection, connect the DIN rail to earth ground.
4. Cables rated for a minimum temperature of 120°C must be used for
the Power Supply Terminal.
5. We suggest using the following cable types for wiring:
• 45ML-5401:
AWG 16 to 24
Varies per module; please refer to the datasheet
System power:
• 12 to 48 VDC, via the ioThinx 4533
Field Power:
• 12/24 VDC, via the ioThinx 4533
Standard Models: -20 to 60°C (-4 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
-40 to 85°C (-40 to 185°F)
45ML-5401 (-T)
System Power: 12 to 48 VDC, 74.1 mA
Field Power: 12/24 VDC, 140.4 mA
Ambient Range: -40°C ≤ Tamb ≤ 75°C (-T models)
Ambient Range: -20°C ≤ Tamb ≤ 60°C (other
models without -T)
No. 1111, Heping Rd., Bade Dist. Taoyuan City 334
Taiwan
EN IEC 60079-0:2018
EN IEC 60079-7:2017
EN IEC 60079-15:2019
Ex ec IIC T4 Gc
UL 20 ATEX 2412X
