- Page 1 4500 Series (45ML) Modules Quick Installation Guide Version 1.2, March 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802045002012 *1802045002012*...
-
Page 2: Package Checklist
Package Checklist • 1 x ioThinx 4500 (45ML) module • 1 x quick installation guide (printed) • 1 x warranty card Installation Installing a 45ML Module on a DIN Rail Step 1: Align the 45ML module side by side with the head/CPU module, making sure that the upper and lower rails are hooked together. - Page 3 NOTE 45MR modules can be installed on the right side of every ioThinx 4500 series head/CPU module, whereas 45ML modules can only be used with an ioThinx 4500 Series product that has the communication bus installed on the left side of the head/CPU module.
-
Page 4: Horizontal Installation
Port 1, Port 2, Serial Green: Transmitting data Port 3, Port 4 connection Amber: Receiving data Off: Disconnected or data is not being transmitted Module Configuration Please refer to the ioThinx 4500 Series User Manual for detailed instructions. - 4 -... -
Page 5: Specifications
Specifications Input Current Varies per module; please refer to the datasheet Input Voltage System power: • 12 to 48 VDC, via the ioThinx 4533 Field Power: • 12/24 VDC, via the ioThinx 4533 Operating Standard Models: -20 to 60°C (-4 to 140°F) Temperature Wide Temp.
