Web Page Item
3. After changing the parameters, click Save Settings.

2.3.3.1 Auxiliary Relay

The CyberData VoIP Intercom provides an auxiliary relay that allows you to control an auxiliary
device co-located with the Intercom via DTMF tones sent from the default dial-out extension.
Note
Controlled Device
Electric Door Strike
Operations Guide
Table 2-7. Intercom Setup Parameters (continued)
The three digit code for the auxiliary relay must be sent in conformance with RFC2833
DTMF generation.
Figure 2-16. Auxiliary Relay Wiring Diagram
Such As
or
Strobe Light
OUT
AC or DC
Power Source
Description
Click on this button to save your configuration settings.
Click on this button to do an audio test. Generates a voice
message for testing the Intercom audio quality and volume.
Link to the Network Setup page.
Link to the SIP Setup page.
Link to the Upgrade Firmware page.
Link to the Home page.
High PIV UltraFast
Solid State
Switching Diode
or
Mechanical
Relay
IN
Output Contacts
AC or DC rated
Depending Upon
Controlled Device
Requirements
-
POWER SUPPLY
(
30 VDC @ 1A
930181B
Installing the VoIP Intercom
Configure the Intercom Parameters
VoIP Intercom
4
3
2
+
DC
1
)
MAX.
