3. On the Home Page, review the setup details and navigation buttons described in
Web Page Item
Device Name
Serial #
Ethernet Address
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
Speaker Volume (0-9)
Microphone Gain (0-9)
Primary Dial-Out
Operations Guide
Figure 2-13. Home Page
Table 2-5. Home Page Overview
Description
Shows the device name.
Device serial number.
Device ethernet address.
Shows the current IP addressing setting (DHCP or static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current default gateway address.
Shows the current DNS server 1address.
Shows the current DNS server 2address.
Shows the current volume level.
Shows the current microphone gain level.
Shows the current primary dial-out number
Link to the Intercom Setup web page.
Link to the Network Setup web page.
930181B
Installing the VoIP Intercom
Configure the Intercom Parameters
Table 2-5.
