2.2.5 Network Connectivity, and Data Rate

When you plug in the Ethernet cable or power supply:
●
•
•
Operations Guide
The square, green Link light above the Ethernet port indicates that the network connection has
been established (see Figure 2-9
auto-negotiated baud rate:
This light is yellow at 10 Mbps.
It is orange at 100 Mbps.
Figure 2-9. Network Connector Prior to Installation
Ethernet
and Figure 2-10). The Link light changes color to confirm the
930181B
Installing the VoIP Intercom
Intercom Setup
Activity
Link
