Operations Guide
Figure 2-7. JP11—RTFM Switch Jumper
for the connector settings.
Table 2-2. Connector Settings
Setting
Network Connection
J-Tag (Factory only)
Terminal Block (see the diagram above, Figure ??)
Call-Button/LED interface
Reset (Factory only)
Microphone Interface
Speaker Interface
Console (Factory only)
RTFM (describe in text)
930181B
Installing the VoIP Intercom
Intercom Setup
CyberData Corporation
9
