- Page 1 Cat. No. W04E-EN-03 SmartSlice GRT1-Series GRT1-PRT PROFIBUS Communication Unit OPERATION MANUAL...
- Page 2 SmartSlice GRT1-Series GRT1-PRT PROFIBUS Communication Unit Operation Manual Revised November 27, 2006...
- Page 4 OMRON Product References All OMRON products are capitalized in this manual. The first letter of the word Unit is also capitalized when it refers to an OMRON product, regardless of whether it appears in the proper name of the prod- uct.
- Page 5 OMRON, 2006 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of OMRON.
-
Page 6: Table Of Contents
Features and Specifications ......Overview of GRT1-Series SmartSlice I/O Units........ - Page 7 Index..........Revision History ........
-
Page 8: About This Manual
Please read this manual carefully so that you understand the information provided before installing or using the GRT1-PRT Unit. Start with the precautions in the following section. They describe the oper- ating environment and application safety measures which must be observed prior to and when using the GRT1-PRT Unit. - Page 9 viii...
- Page 10 WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS...
- Page 11 The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for the products: •...
- Page 12 PERFORMANCE DATA Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements.
-
Page 14: Precautions
Conformance to EC Directives ........ -
Page 15: Intended Audience
This manual provides information for Installing and operating the OMRON GRT1-PRT PROFIBUS Communication Unit. Be sure to read this manual before attempting to use the Unit and keep this manual close at hand for refer- ence during operation. !WARNING... -
Page 16: Operating Environment Precautions
Operating Environment Precautions • The PLC outputs may remain ON or OFF due to deposits on or burning of the output relays, or destruction of the output transistors. As a counter- measure for such problems, external safety measures must be provided to ensure safety in the system. -
Page 17: Application Precautions
• When adding a new device to the network, make sure that the baud rate is the same as other stations. • When adding a new SmartSlice I/O Unit to the Communication Unit, make sure that the GRT1-PRT PROFIBUS Communication Unit is powered down, to prevent unexpected results when starting up the new station. -
Page 18: Conformance To Ec Directives
Conformance to EC Directives • Take appropriate measures to prevent foreign objects from entering the unit when mounting or wiring it. Failure to do so, may result in unit dam- age, electric shock or fire. • Use crimp terminals for wiring. Do not connect bare stranded wires directly to terminals. -
Page 19: Conformance To Ec Directives
PROFIBUS units should be installed as follows, for the complete configuration to meet the EC directives: 1,2,3... 1. The units are designed for installation inside control panels. All units must be installed within control panels. 2. Use reinforced insulation or double insulation for the DC power supplies used for the communication power supply, internal circuit power supply, and the I/O power supplies. -
Page 20: Features And Specifications
Preparations for Use ........ -
Page 21: Overview Of Grt1-Series Smartslice I/O Units
SmartSlice I/O configurations can be very compact, consisting of only a few I/O points, but they can also be extended, to up to 64 I/O slices. The slice con- figuration can also be subdivided over two or more blocks using local exten- sion units and extension cables, as shown in the figure above. -
Page 22: Grt1-Prt Profibus Communication Unit
Appendix A PROFIBUS Technology. Manage Multiple A single PROFIBUS Communication Unit with up to 64 connected SmartSlice SmartSlice I/O Units as I/O Units can be managed as a single slave device from the PROFIBUS DP- One Slave V1 Master. I/O Data Exchange... -
Page 23: System Configuration
The PROFIBUS Communication Unit automatically detects the Master’s com- Recognition munication baud rate, so it is not necessary to set the baud rate. (If the Mas- ter’s baud rate has been changed, the PROFIBUS Communication Unit must be turned OFF and then ON again to change its baud rate.) -
Page 24: Specifications
• Switch 1: Create / Enable Registration Table • Switch 2: Not used. • Switch 3: Automatic Restore • Switch 4: Backup Trigger Indicators 6 LEDs, indicating Unit status, Slice I/O status and PROFIBUS status: Unit status: RUN (Green LED) ERR (Red LED) UNIT PWR (Green LED) - Page 25 9-pin sub-D female connector (#4/40 UNC thread) Termination according to EN50170 provided by the cable connector Unit device address range 0 ~ 99, set through the rotary switches on the front baud rates supported Selectable through the configurator: • 9.6 kbit/s •...
-
Page 26: Grt1-Prt Configuration
Container and provides its own User Interfaces. It can access GRT1-PRT and SmartSlice I/O Unit data through the PROFIBUS Master unit and present that to the user. It can also save the settings, using the features of the FDT Con- tainer program. - Page 27 The drawback of the GSD file is that- unlike the GRT1-PRT DTM - it only pro- vides setting options for PROFIBUS DP and PROFIBUS DP-V1. The GSD file does not provide the means to initiate parameter data transfer via PROFIBUS DP-V1 Class 2 messages.
-
Page 28: Basic Operating Procedure
The following diagram provides an overview of the installation procedures. For experienced installation engineers, this may provide sufficient informa- tion. For others, cross-references are made to various sections of this manual where more explicit information is given. Mount the GRT1-PRT PROFIBUS Unit and... -
Page 29: Preparations For Use
PROFIBUS address. 5. Turn ON the power to the Unit and the I/O. 6. Turn ON (from OFF to ON) DIP switch 1 on the front of the PROFIBUS Communication Unit. When switch 1 is turned ON, the existing SmartSlice I/O Unit configuration (connection order and I/O size) is registered in the PROFIBUS Communication Unit as a registered table. -
Page 30: Installation And Wiring
Installing the GRT1-PRT Unit ........ -
Page 31: Unit Components
2-1-1 Nomenclature The illustration below shows the Status LED indicators, the PROFIBUS address switches, and a 9-pin female sub-D connector on the front side of the PROFIBUS Communication Unit. Each of these components are explained in the following sections. Rotary switches Set the Unit's address as a PROFIBUS Slave. -
Page 32: Switch Settings
PROFIBUS device address of the Unit. The address can be set in the range of 00 through 99 (decimal). The device address on the Unit must be the same as the address used in the master’s configuration. The device address is used to uniquely identify PROFIBUS Communication Unit on the PROFIBUS DP network. - Page 33 BACK Backup Trigger. DIP Switch 1: REGS If DIP switch 1 is turned from OFF to ON while the Unit’s power is ON, the Create / Enable existing SmartSlice I/O Unit configuration (connection order and I/O size) is Registration Table registered in the PROFIBUS Communication Unit as a registered table.
-
Page 34: Power Supply Connector
Power supply terminals as the PROFIBUS Communication Unit. 2-1-5 PROFIBUS Connector The PROFIBUS connector on the font of the Unit is a 9-pin female sub-D con- nector, as recommended by the PROFIBUS standard EN50170. Pin No. Signal... -
Page 35: Installing The Grt1-Prt Unit
• Ensure that the power supplies for the PROFIBUS Communication Unit and the SmartSlice I/O Units and the external I/O are wired correctly. • Provide separate conduits or ducts for the I/O lines to prevent noise from high-tension lines or power lines. - Page 36 To install a PROFIBUS Communication Unit on the DIN Rail, press the Unit onto the DIN Track from the front. Press the Unit firmly until it clicks, indicating that the Unit’s DIN Rail Mounting Hooks have all locked onto the DIN Rail.
-
Page 37: Connecting The Profibus Unit And Smartslice I/O Units
Connecting Additional SmartSlice I/O Units Connect additional SmartSlice I/O Units by aligning the sides of the Units and sliding in the next Unit from the front. Up to 64 SmartSlice I/O Units can be connected to one PROFIBUS Communication Unit. - Page 38 Plates on both sides of the System. First hook the bottom of the End Plate on the bottom edge of the DIN Rail (1), attach the top of the End Plate, and pull the End Plate down onto the top edge of the DIN Rail (2). Tighten the End Plate’s securing screw.
-
Page 39: Wiring The Grt1-Prt
SmartSlice I/O Units at the de- sired point with a GRT1-PD2 I/O Power Supply Unit and provide a sepa- rate external I/O power supply. 3. It is also possible to provide a separate external I/O power supply at a Left Turnback Unit (GRT1-TBL). Note 1. -
Page 40: Wiring Methods
Connect the power supply wires (24 VDC) to the PROFIBUS Communication the Units Unit’s screwless clamping power supply terminals. If pin terminals are used on the wire ends, the pin terminals can just be inserted to wire the power. Release button Holes for wires... - Page 41 The power supply for I/O devices is supplied through the PROFIBUS Commu- nication Unit’s screwless clamping power supply terminals. If pin terminals are used on the wire ends, the pin terminals can be inserted to wire the power. Release button...
-
Page 42: Connecting The Turnback Units
Wiring the GRT1-PRT Section 2-3 2-3-3 Connecting the Turnback Units When a SmartSlice I/O System is divided into blocks to expand the system, connect a GRT1-TBR Right Turnback Unit to the GRT1-TBL Left Turnback Unit with a GCN2-100 Turnback Cable. Note Power is not supplied through the GCN2-100 Turnback Cable. -
Page 43: Setting Up A Profibus Network
The total cable length of the bus depends on the cable and the selected baud rate. Also, RS-485 specifies a maximum of up to 32 devices - master and slave devices - per line segment. - Page 44 0.64 mm Core cross section 0.34 mm Note The PROFIBUS standard EN 50170 also specifies a Type B cable with differ- ent cable characteristics. Use of Type B cable is no longer recommended. Maximum PROFIBUS The transmission speed defines the maximum advised cable distance or Cable Length cable segment in metres before the use of a repeater is recommended.
-
Page 45: Bus Termination
In order to minimize cable reflections and ensure a defined signal level on the data lines, the data transfer cable must be terminated at both ends with a ter- minating resistor combination. The bus termination diagram is shown on the left. -
Page 46: Profibus Cable Connector
A standard 9-pin sub-D plug can only be used if the PROFIBUS DP Master Unit is not at the start or the end of a bus segment, or on a stub line at a baud rate of 500 kbit/s or less. -
Page 47: Installation Of Configuration Software
I/O configuration and setting the parameters of both the GRT1-PRT as well as individual SmartSlice I/O Units. Note To fully utilize the features of the GRT1-PRT and the SmartSlice I/O system, a PROFIBUS DP-V1 Class 2 capable Master Unit and DTM are required. The OMRON CS1/CJ1W-PRM21 Master units provide this functionality as of ver- sion 3.0. -
Page 48: Grt1-Prt Gsd File
Updating the Device After installation of the GRT1-PRT DTM the Device Catalogue in the FDT Catalogue Container needs to be updated, to show the new GRT1-PRT DTM in the list of available devices. For Cx-Profibus the following procedure applies 1,2,3... -
Page 50: Setup And Operation
Setup Using the DTM ........ -
Page 51: Station Address Settings And I/O Allocation
×1 ×10 The valid address range is 00 to 99 can be set as long as this number is not set on another station (Master or Slave) in the network. However, the following must be observed. !Caution In the messaging services the address 00 is reserved. This means that when... -
Page 52: Smartslice I/O Allocation To The Grt1-Prt Unit
3-1-3 SmartSlice I/O Allocation to the GRT1-PRT Unit The SmartSlice I/O Units’ I/O data is mapped in the I/O memory of the GRT1- PRT, from which it is transferred to the PROFIBUS Master unit. This allocation is done automatically and determined by the SmartSlice I/O Unit’s type. The figure below shows this mapping. - Page 53 5. Word sized SmartSlice I/O Units, e.g. GRT1-AD2, GRT1-DA2V are mapped to one or more words. 6. Total size of mapped I/O data can be 64 words output and 64 words input. I/O Allocation Example I/O data is mapped to the GRT1-PRT Units I/O data blocks in the same order the SmartSlice I/O Units are connected to the PROFIBUS Communication Unit, regardless of the I/O Units’...
- Page 54 SmartSlice I/O Units was completed successfully. 1: Restore failed Communication Unit Error Flag This is the overall Unit status flag. This flag will be ON if any one of the 0: Normal other flags (bits 0 to 13) is ON.
-
Page 55: Unit Functions
SmartSlice I/O Units’ power supply is ON. The registered table is enabled if DIP switch 1 is ON when the power is turned ON. If DIP switch 1 is OFF when the power is turned ON, the registered table is disabled and the Com- munication Unit will automatically detect the actual I/O configuration and start communication. - Page 56 Unit Functions Section 3-2 Comparison with the When DIP switch pin 1 (REGS) is ON and an I/O configuration table has been Registered Table registered in the Communication Unit, the actual I/O configuration is automat- ically compared to the registered table when the power is turned ON. A verifi- cation error will occur if a registered I/O Unit cannot join I/O communication or an unregistered I/O Unit is detected.
-
Page 57: Backup Function
Backup Procedure 1,2,3... 1. Verify that the power is ON, DIP switch 1 (REGS) is ON, and all of the SmartSlice I/O Units are participating in I/O communication. 2. Turn DIP switch 4 (BACK) ON, then OFF, and then ON again within 3 s to start the back up. - Page 58 1. Turn OFF the SmartSlice I/O System’s power supply and the I/O power supply. 2. Release the locks on the front of the SmartSlice I/O Unit that must be re- placed and remove the terminal block. The wiring can remain connected.
-
Page 59: Online Replacement Function
4. Only replace one I/O Unit at a time. 5. Always replace the I/O Unit with the same model of I/O Unit. If a Unit is re- placed with a different model, there may be unexpected outputs and the re- store operation may not be completed properly. -
Page 60: I/O Communication Error History Monitor
The PROFIBUS Communication Unit can record the 64 most recent internal SmartSlice Communication Unit errors in the Unit’s error history. When more than 64 errors occur, the oldest entry is deleted to make space for the newest error entry. The communication error history can be read from the GRT1-PRT DTM or via messaging services. -
Page 61: Setup The Grt1-Prt Configuration
Master Units Operation Manual (W409) for more information on how to assemble a network. The figure below shows Cx-Profibus with an assembled network in the left window pane and the Device Catalogue opened in the main window pane. To define the I/O Configuration of the GRT1-PRT SmartSlice Communication Unit, double-click the device in the Network view using the left mouse button. -
Page 62: Setup Using The Dtm
GRT1-PRT DTM window which pops up after double-clicking the GRT1-PRT entry in the Network View is shown below. Note The buttons on the bottom will be enabled only when the DTM is on-line. Parameter Area Tab The Parameter Area Tab, shown above, defines the parameter settings for the GRT1-PRT. - Page 63 Group Setting The Group Setting selects to which of 8 groups the GRT1-PRT will belong. This setting allows the user to control input and output data on specific groups of devices using the broadcast command. Refer to Appendix A-4 Bus Access Protocol for more information on the broadcast command.
- Page 64 1. Select the first row and double-click it using the left mouse button. A drop- down list will appear (see figure below). 2. From the drop-down list select the type of slice which is in this first slot, right next to the GRT1-PRT.
- Page 65 Section 3-3 Note 1. Not shown in the list is the first input word, containing the GRT1-PRT Unit status word (refer to section 3-1-3 SmartSlice I/O Allocation to the GRT1- PRT Unit for an explanation on this word). The GRT1-PRT DTM automat- ically adds the status word to the I/O Configuration.
- Page 66 Editing SmartSlice I/O Unit After making the I/O configuration selection, the settings of individual Smart- Settings Slice I/O Units can be set or changed. To do this, perform the following steps. 1,2,3... 1. Select the SmartSlice I/O Unit in the I/O Configuration.
-
Page 67: Setup Using The Gsd File
Setup the GRT1-PRT Configuration Section 3-3 within the DTM. In case a mismatch is found, a warning screen will pop up to notify the user. Reset Button Pressing the Reset button will initiate a system reset, i.e. the GRT1-PRT as well as the attached SmartSlice I/O Units will be reset. - Page 68 Select a module which is not marked with an asterisk • After a word has been filled up, a new word must be started by select- ing again the next I/O module not marked with an asterisk.
- Page 69 Word #4 Setting Parameters After selecting the I/O Configuration additional parameter settings can be made in the other tabs. These tabs will not be shown here, as they are similar to the settings explained in the previous section. Parameter Tab The Parameter Tab contains the setting for the FINS Fragment Length (See FINS Fragment Length Setting on page 44).
-
Page 70: Mapping I/O Data
The CS1/CJ1W-PRM21 PROFIBUS Master Unit provides a means to map individual I/O Configuration modules to specific memory areas. For information on how to map the I/O data on to the PLC memory, refer to the CS1/CJ1 PROFIBUS Master unit Operation Manual (W409). -
Page 71: Operating The Network
1. Select the GRT1-PRT in the Network View and right click the mouse. 2. From the context menu, which pops up, select the Diagnosis option. Note Only one GRT1-PRT can be monitored at a time. Opening two or more DTMs in monitoring mode may not function properly. - Page 72 Operating the Network Section 3-4 PROFIBUS The colour of the LED indicators in the window indicate either error (Red) or a Communication Status status (Green). The PROFIBUS Communication status LED indicators repre- sent the status bits in the GRT1-PRT Diagnostics message sent to the PROFIBUS Master Unit.
-
Page 73: Monitoring The Smartslice I/O System
I/O Error History Tab of the Diagnosis window. SmartSlice I/O Status When selecting the I/O Module Tab, the window as shown below will show up. In case an on-line connection to the GRT1-PRT is open, the View button will be enabled. Selecting a SmartSlice I/O Unit and pressing the View button will open a status window for the selected SmartSlice I/O Unit. -
Page 74: Remote Communication Characteristics
CS/CJ-series PROFIBUS DP Master Units Operation Manual (W409). I/O Response Time The I/O response time is the time it takes from the reception of an input signal at an Input Unit in the SmartSlice I/O System to the output on an Output Unit in the SmartSlice I/O System after being processed by the PLC program. - Page 75 2.27 + 0.077 × number of words (ms) (See note 1) Note 1. The number of words refreshed is the total number of words in the I/O Area allocated to the Slaves, including any unused words between the allocated words. For example, if there are only two Input Slaves with station address- es 1 and 5, the 5 input words for stations 1 through 5 would be refreshed even though the input words for stations 2, 3, and 4 are unused.
- Page 76 Slice Bus Communication The SmartSlice bus communication cycle time is the delay in the SmartSlice Cycle Time (T I/O System from the end of communication with one I/O Unit until the start of communication with the next Unit. Communication Unit...
-
Page 77: Message Communication Characteristics
Communication Time to The time required for a message to be sent is the same as the PROFIBUS the PROFIBUS cycle time, since the acyclic message are sent at the end of a cycle, prior to Communication Unit the next one. -
Page 78: Troubleshooting And Maintenance
PROFIBUS Errors ........ -
Page 79: Overview
DC24V INPUT INPUT Note Not shown in the figure above is a Turnback Unit. The Turnback Unit also pro- vides I/O PWR, UNIT PWR and TS LED Indicators. The LED indicators can be used to determine the following categories of errors •... -
Page 80: Power Supply Errors
Section 4-2 4-2-1 Power Supply Errors Errors in the Power supply of the Unit or the external I/O are indicated by the UNIT PWR and I/O PWR LED Indicators. Troubleshooting UNIT The UNIT PWR LED Indicator shows whether or not sufficient power is sup-... -
Page 81: Unit System Errors
4-2-2 Unit System Errors If power supply to the Unit and the SmartSlice I/O Units is correct, the Unit will start initialization at power up. During the Initialization process the RUN LED indicator will remain OFF. Once the initialization has been completed cor- rectly, the RUN LED indicator will be ON. -
Page 82: Profibus Errors
Probable cause Correction Not lit No PROFIBUS Communication error encountered. The Unit is exchanging I/O data with the Master Unit. Flashing The PROFIBUS configuration is not correct. There is • Check the configuration and the parameter data of however communication with Master Unit. -
Page 83: Other Errors
2-4-2 Bus Termination). rectly. Note 1. If two or more SmartSlice I/O Units do not match with the PROFIBUS I/O configuration, the diagnostics message will only contain the error flags of the first mismatching SmartSlice I/O Unit. 2. Selecting the COM Status module applies to the use of the GSD file in third-party Configuration software. -
Page 84: Troubleshooting Profibus Communication
OFF-LINE or STOP mode. Check the Master Status 1 Word (Master CIO Word n+5, bit 00 to bit 03, see Note). If • The Master’s BST LED indicator is OFF Unit is in OFF-LINE or STOP mode: The Master Unit may have been config- ured to maintain its current mode (last •... - Page 85 OFF-LINE or STOP mode. Check the Master Status 1 Word (Master CIO Word n+5, bit 00 to bit 03, see Note). If • The Master BST LED indicator is OFF Master Unit is in OFF-LINE or STOP mode: •...
-
Page 86: Smartslice I/O Unit Error History
Note n = CIO 1500 + (25 x unit number). 4-3-3 SmartSlice I/O Unit Error History The PROFIBUS Configurator can read the error history details of the most recent errors that occurred in the SmartSlice I/O Units. Error History Tab Page... - Page 87 Volatile 1st byte 2nd byte (Hex) 0002 WDT error 0x00 0x00 Replace the Unit if the error occurs frequently. 0370 Verification error (Slave missing) Connect the missing Unit and restart. No 0372 Verification error (unregistered 0x80: Node address Remove the unregistered Unit and...
-
Page 88: Maintenance
• Regularly wipe the Unit with a dry, soft cloth. • If a spot cannot be removed with a dry cloth, dampen the cloth with a neu- tral cleaner, wring out the cloth and wipe the Unit. -
Page 89: Replacing The Unit
Unit and return it to the nearest OMRON dealer. Note 1. In order to prevent faulty operation be sure to turn off the power to all mas- ter and slave devices before replacing the Unit. 2. When replacing the Unit, do not reconnect it to the Network before carrying out the procedures listed below. -
Page 90: Profibus Technology
In general, the PROFIBUS communication protocol is based on the Open System Interconnection (OSI) refer- ence model in accordance with the international standard ISO-7498 (see the following illustration). The model defines 7 layers of communication functions, three of which - layers 1, 2, and 7 - are used in PROFIBUS. DP-Profiles... - Page 91 Appendix A PROFIBUS Technology PROFIBUS DP uses layers 1 and 2, and the user interface. Layers 3 to 7 are not defined for PROFIBUS DP. The User Interface Layer defines the interface functions for specific application areas, i.e. the PROFIBUS DP basic functions and communication profiles.
- Page 92 The token message, a special message for passing access rights from one master to the next master, must be passed around the logical token ring - once to each master - within a specified target rotation time. Each master executes this procedure automatically.
- Page 93 CLEAR state. Slave devices use a watchdog to detect failures of the master or the bus. If no data exchange with the master occurs within the set watchdog time interval, the slave automatically switches its outputs to the fail-safe mode.
- Page 94 When comparing the two configuration technologies, a GSD file only provides information on the device char- acteristics and configuration options. It has no GUI of its own, nor can it connect to the device itself. A GSD file always requires a separate configurator program to interpret the data. In the FDT/DTM concept all these device related functions are included in the DTM.
-
Page 96: Slave Diagnostics Message
Description Diag.Station_Non_Existent This bit is set by the Master Unit if the Unit does not respond to any of the request messages sent by the master. If this bit is set the diagnostic bits contains the state of the last diagnostic message or the initial value. The slave device sets this bit to zero in case of a correct response. - Page 97 Master Unit receives more diagnostic information than it can enter in its diag- nostic buffer. Slave Diagnostics Byte 4: Master PROFIBUS Address This byte contains the PROFIBUS address of the Master Unit, which parameterized the slave. If the slave is not parameterized correctly, the byte contains FF (Hex) or 255 (Decimal).
- Page 98 Slave Diagnostics Bytes 5 to 6: Ident Number Slave Diagnostics Bytes 5 and 6 contain the PROFIBUS Ident Number of the slave device. The Ident number uniquely identifies the type of device. For the GRT1-PRT PROFIBUS DPV1 slave the Ident number is 098F (Hex).
- Page 99 No SmartSlice / Data invalid Note If two or more SmartSlice I/O Units do not match with the PROFIBUS I/O configuration sent by the PROFIBUS Master Unit, the diagnostics message will only contain the error flags of the first mismatch-...
-
Page 100: Explicit Messages
Note The number of bytes designated for Class ID, Instance ID, and Attribute ID depend on the Master Unit. When sent from an OMRON Master, the Class ID and Instance ID are 2 bytes (4 digits), and Attribute ID is 1 byte (2 digits). - Page 101 Appendix C Explicit Messages Service Code For normal completion, the value when the leftmost bit of the service code specified in the command turns ON is stored as shown in the following table. Function Command service code Response service code...
- Page 102 The 4 bits allocated to each SmartSlice I/O Node have the following functions: Bit 0 Warning (Minor error) Bit 1 Alarm (Major error) Bit 2 Reserved Bit 3 Reserved Note The Warning/Alarm details depend on the Communication Unit. Refer to the Unit’s operation manual.
- Page 103 Reads the Alarm data of the connected SmartSlice I/O Unit from the PROFIBUS Communication Unit. The data is read using the EXPLICIT MESSAGE SEND command (2801). The command data is written in words starting from D01000 in the PLC and the response data is stored in words starting from D02000.
- Page 104 20 00 Number of slave alarm data: 32 (20 Hex) Status of slave #4, Status of slave #3 (2 bits each) D02005 00 00 Status of slave #8, slave #7, slave #1, slave #2 (2 bits each) D02006 to D02020 (continue)
- Page 105 Appendix C Explicit Messages...
-
Page 106: Index
Auto-CLEAR Automatic restore Generic Slave DTM Extensions Backup function Configuration convention Basic Operating Procedure Diagnostics Update Delay Baud rate Error on Cyclic Data Exchange B-line GRT1-PRT Bus connector Automatic restore Backup function Bus termination Configuration See Wiring I/O Data mapping... - Page 107 Operating the Network DTM versus GSD file Operation modes GSD file technology See Network Operation modes OSI reference model Layer 1, Physical Layer Layer 2, Data Link Layer I/O data allocation Layer 7, Application Layer I/O data sizes outputs Table comparison precautions...
- Page 108 Setup GRT1-PRT Configuration Shock resistance Slave devices Slave diagnostics Extended data Channel related Device related Module related SmartSlice I/O Unit errors SmartSlice I/O Units Online replacement Troubleshooting Table comparison Table registration Token passing Trademarks transferring I/O memory data transferring I/O memory files...
-
Page 110: Revision History
Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. W04E-EN-01 Revision code The following table outlines the changes made to the manual during each revision. The page numbers of a revi- sion refer to the previous version.
