FLASHFORGE 3D PRINTER Creator Max User Manual page 44

6. Click the Print icon, then change the settings as appropriate for your filament type and model.
· Preview: Check the Preview box if you want to preview the model after slicing is done.
· Print When Slice Done: Because we are printing from the SD™ card, uncheck this box to save
· Machine Type: Select Flashforge Creator Max 3D Printer.
· Material Right: Select the type of filament you are using.
· Material Left: Select the type of filament you are using.
· Supports: If your model has overhanging elements, enable the Supports option.
· Raft: It is recommended to enable the Raft option.
· Resolution: It is recommended to select the Standard option.
· More Options: It is recommended to leave them at the default values.
7. Click OK to save the Gcode file to the SD™ card. You can rename the file as desired and save it as
either a .g or .gx file. Files with a .gx extension can be previewed, while .g files cannot.
8. Eject the SD™ card, then plug it into the SD card slot on the printer.
9. Power on the printer.
10. Ensure that the build plate is leveled and that filament is loaded.
11. Touch the Print button on the printer display.
12. Touch the SD card button, then locate and load your model file.
Print
the Gcode file to the SD card.
Preheat Tool
43
