Rear Panel - TEXIO PSW-A Series Instruction Manual

1.2.2.

Rear Panel

Low voltage 720W models
PSW-720M160A, PSW-720L80A, PSW-720L30A (Type II)
Analog control
connector
Sense-
terminal
Output
terminal(-)
LAN
Low voltage 1080W, 360W models
PSW-1080M160A,
PSW-1080L80A,
PSW-1080L30A
Type III
( )
Sense+
terminal
LAN
AC Input
SER.NO. LABEL
N
LAN
12
USB B
Port
SER.NO. LABEL
AC 100 240V
47 63Hz
1000VA MAX.
PSW-360M160A,
PSW-360L80A,
PSW-360L30A
Type I
(
L
AC 100 240V
47 63Hz 1500VA MAX.
Output
terminal(+)
Fan
AC Input
)
AC 100 240V
47 63Hz 500VA MAX.
LAN
