TEXIO PSW-A Series Instruction Manual page 63

product in series. Please read this overview carefully before beginning
series operation of this product.
Limitations
Display
OVP/ OCP
(Overvoltage/overcur
rent protection)
Output monitor signal The voltage monitor (VMON) and current monitor
Remote sensing
function
Output
voltage/current
control by external
signal input
Slew rate
Internal resistance
setting value
Bleeder circuit control Bleeder circuit settings can only be made on the
Rated output during one-control series operation
Model name
PSW-360L30A
PSW-360L80A
PSW-360M160A
PSW-720L30A
PSW-720L80A
Description
Only the master unit displays the current value.
The voltage value is displayed on both the master
and slave units. For the voltage value, add the
voltages of the master and slave units.
OVP/OCP detection is performed on the master
unit. The OVP/OCP function of the slave unit is
disabled.
When the master unit detects OVP/OCP, the output
is turned off, and at the same time, the output of the
slave unit is also turned off.
(IMON) can only be used on the master unit.
The voltage monitor (VMON) signal represents the
total voltage of all products connected in series.
Remote sensing function can be used.
Refer to page
External voltage or external resistance can be input
as external signal.
Output voltage/current control using external
signals is valid only for the master unit.
The current slew rate operates at the set value
speed from the master unit.
The voltage slew rate operates at twice the speed
set from the master unit.
This will be twice the value set on the master unit.
master unit. The slave unit bleeder circuit is always
enabled (on).
Single unit
30V, 36A
80V, 13.5A
160V, 7.2A
30V, 72A
80V, 27A
49 for more information.
2 units
60V, 36A
160V, 13.5A
320V, 7.2A
60V, 72A
160V, 27A
