1080W Type Iii - TEXIO PSW-A Series Instruction Manual

*2 From No-load to Full-load, constant input voltage. Measured at the sensing
point in Remote Sense.
*3 Measure with JEITA RC-9131B (1:1) probe
*4 Measurement frequency bandwidth is 10Hz to 20MHz.
*5 Measurement frequency bandwidth is 5Hz to 1MHz.
*6 From 10% to 90% of rated output voltage, with rated resistive load.
*7 From 90% to 10% of rated output voltage, with rated resistive load.
*8 Time for output voltage to recover within 0.1% + 10mV of its rated output for a
load change from 50 to 100% of its rated output current.
*9 For load voltage change, equal to the unit voltage rating, constant input
voltage.

10.3. 1080W Type III

Model
Rated Output Voltage
Rated Output Current
Rated Output Power
Power Ratio
Constant Voltage Mode
Line Regulation (*1)
Load Regulation (*2)
Ripple and Noise (*3)
p-p (*4)
r.m.s (*5)
Temperature coefficient
Remote sense
compensation voltage
(single wire)
Rise Time (*6)
Rated Load
No Load
Fall Time (*7)
Rated Load
No Load
Transient response
time (*8)
Constant Current Mode
Line regulation (*1)
Load regulation (*9)
Ripple and noise
r.m.s
Temperature coefficient
Protection Function
Over voltage protection (OVP)
Setting range
PSW-
1080
Unit L30A
V 30
A 108
W 1080
3
mV 18
mV 20
mV 100
mV 14
100ppm/ ºC
V 0.6
ms 50
ms 50
ms 50
ms 500
ms
mA 113
mA 113
mA 216
200ppm/ ºC after a 30-minute warm-up
V 3-33
146
PSW- PSW-
1080 1080
L80A M160A
80 160
40.5 21.6
1080 1080
3 3.2
43 83
45 85
100 100
14 20
after a 30-minute warm-up
0.6 0.6
50 100
50 100
50 100
500 1000
1 1
45.5 26.6
45.5 26.6
81 45
8-88 16-176
PSW- PSW-
1080 1080
M250A H800A
250 800
13.5 4.32
1080 1080
3.125 3.2
128 403
130 405
120 200
15 30
1 1
100 150
100 150
150 300
1200 2000
2 2
18.5 9.32
18.5 9.32
30 15
20-275 20-880
