TEXIO PSW-A Series Instruction Manual page 19

High voltage 720W models
PSW-720H800A, PSW-720M250A (Type II)
Analog control
connector
Sense-
terminal
Chassis
ground
Output
terminals -V
LAN
High voltage 1080W, 360W models
PSW-1080H800A,
PSW-1080H250A
Type III
( )
Sense+
terminal
V SN.C. S V
LAN
V SN.C. S V
LAN
13
USB B
port
SER.NO. LABEL
AC 100
47 63Hz
AC Input
SER.NO. LABEL
N L
AC 100 240V
47 63Hz 1500VA MAX.
Output
terminals +V
Fan
240V
1000VA MAX.
AC Input
PSW-360H800A,
PSW-360M250A
Type I
( )
V SN.C. S V
AC 100 240V
47 63Hz 500VA MAX.
LAN
