BACNET DATA TABLES

BACnet Data Tables
CAUTION
Please note that each time a command is written to a configuration property,
(noted by a "cp" in front of the BACnet object name) the data is stored in
the unit controller's non-volatile or Flash memory. Writing to Flash memory
is an operation that has a finite limit. For this reason, the number of writes
made to BACnet objects linked to configuration properties must be limited
to avoid damage to the hardware.

BACnet Network Parameters

Table 3: Analog Inputs
Object
Point Name Type/
Instance
Local Space
AI:1
Temperature
Leaving Water
AI:2
Temperature
Entering Water
AI:3
Temperature
Discharge Air
AI:4
Temperature
Local Setpoint Adjust AI:5
Compressor 1 Suction
AI:6
Temperature
Compressor 2 Suction
AI:7
Temperature
Brownout Voltage
AI:8
Reading
Local Space Humidity AI:9
Return Air Temperature AI:10
Parameter is stored in FLASH/EEPROM (non-volatile memory) in either the communication module or in the unit controller . If Non-volatile Memory = Y, then the
1
value is saved through a power cycle . Writes to this parameter must be limited . If Non-volatile Memory = N, the value is not saved through a power cycle .
R = Read Only, W = Writeable, C = Commandable
2
3 A Null value is equal to 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not using that particular temperature
value .
DAIKIN APPLIED
BACnet Object
Range/Default
Name
0 to 158ºF
-17.77 to 70ºC
LocalSpaceTemp
Default:
68ºF / 20ºC
0 to 158°F
-17 .77 to 70°C
LWT
Default:
32ºF / 0ºC
0 to 158°F
-17 .77 to 70°C
EWT
Default:
32ºF / 0ºC
0 to 158°F
-17 .77 to 70°C
DischAirTemp
Default:
32ºF / 0ºC
55 to 95ºF
12.78 to 35ºC
LocalSetpt
Default:
32ºF / 0ºC
0 to 158°F
-17 .77 to 70°C
Comp1SuctionTemp
Default:
32ºF / 0ºC
0 to 158°F
-17 .77 to 70°C
Comp2SuctionTemp
Default:
32ºF / 0ºC
0 to 4095 counts
Brownout
Default: 0
LocalSpaceRH 1 to 100%
0 to 158°F
-17 .77 to 70°C
RAT
Default:
32ºF / 0ºC
The following section contains relevant information needed to
integrate a MicroTech WSHP into the BACnet network .
The Network Configuration,
Space Temperature Setpoints
details . Also see BACnet PICS .
NOTE: Changing a temperature setpoint's minimum or
maximum value may result in an "Out of Range"
error . This is due to the internal Fahrenheit to Celsius
conversion . To prevent this error from occurring,
use an offset of 0.1º when writing to a minimum or
maximum temperature setpoint value .
Read/ Non-
Write volatile
Access Memory
2 1
Reflects the value provided from either a room temperature
R N
sensor or thermostat input .
Reflects the leaving water temperature sensor value, if
R N
installed and configured with a valid input.
Reflects the entering water temperature sensor value, if
R N
installed and configured with a valid input.
Reflects the discharge air temperature sensor value, if
R N
installed and configured with a valid input.
Reflects the value of the selected control temperature
(space, return air, average) long range reference setpoint .
Applies when configured for long range setpoint adjust
(baseboard configuration switch 5 is on) and is enabled
R N
by MSV:14 .
This setpoint is also used to calculate the effective heating/
cooling setpoints . See
Indicates the compressor #1 suction line temperature
R N
sensor value .
Indicates the compressor #2 suction line temperature
R N
sensor value .
The compressr brownout voltage used for factory-unit
controller calibration . This reference value (in counts) is
R N
compared to the brownout trip and recover setpoints to
determine if a brownout condition exists . Also see AV:9 .
Reflects the value of the indoor relative humidity sensor, if
R N installed and configured with a valid input. The input is also
used to calculate the local space dewpoint value .
The value of the room/return air temperature (RAT), if
R N
installed and configured with a valid input.
8
Effective Occupancy Modes, and
sections provide additional
Description
3
3
3
3
3
Effective Occupancy Modes .
3
3
