1
USING THE UTILITY FOR ID-RP3
Programming the repeater
D Programming through a USB cable (Continued)
3. Reading the data from the repeater
Read the operating frequency and operating mode
data (DV/FM/MIX) to the utility.
z Click " " or select "Read <- Repeater" in the
<Program> menu to read the data.
• [TX] and [RX] indicators on the repeaterʼs front panel
blink while reading.
4. Editing the data
Edit the setting data. See the Utility for ID-RP3 HELP
that comes with the utility for details.
5. Writing the data to the repeater
z Click " " or select <Write -> Repeater> in the
<Program> menu to write the data.
• [TX] and [RX] indicators on the repeaterʼs front panel
blink while writing.
TIP: Assigning repeater ID
Assign different repeater IDs for each repeater when
multiple repeaters are connected.
1. Connect your PC to the [USB] port of the target
repeater.
2. Turn ON the repeater.
3. Open the Initial Setup window.
4. Set the COM port number to the port that the
USB cable is connected to, and then click <OK>.
programming screen is displayed.
• The
5. Select <Rewrite ID> in the <Tool> menu.
window is displayed.
• The "Rewrite ID"
NOTE:
• Backup the read data to prevent data loss.
• If multiple repeaters are connected and recognized,
all repeater data will be read.
TIP: You can also edit the setting file (icf) saved on
your PC. Click " " or select <Open...> in the <File>
menu to open the file.
L Confirm the file's Setting type (Single unit or Multiple
Units) matches with the current repeater settings.
TIP:
You can save the setting data to your PC. Click
" " or select <Save As...> in the <File> menu to
save the data.
L If multiple repeaters are connected, the settings for all
repeaters are saved as a single setting file (icf).
6. Select an ID to assign, and then click <Write>.
7. Select the Setting type on the Toolbar according
to the number of the connected repeater.
(<Setting Type>)
5
