Nexperia
Reference
Qty
Value
R30
1
3k-1%
R31
1
TBD
TP1
1
GATE_WT_S
TP2
1
PHASE_W
TP3
1
GATE_WB_S
TP4
1
GATE_VT_S
TP5
1
PHASE_V
TP6
1
GATE_VB_S
TP7
1
GATE_UT_S
TP8
1
PHASE_U
TP9
1
GATE_UB_S
TP10
1
ADC_A
TP11, TP12,
6
GND
TP13, TP14,
TP15, TP16
TP18, TP19,
3
VIN
TP20
U1
1
LTC6101HV
UM90029
Submit document feedback
User manual
Footprint
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_2010_5025Metric_Pad1.40x2.65mm_HandSolder
Connectors:TestPoint_3Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_3Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_3Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch2.54mm_Drill1.5mm
TestPoint:TestPoint_THTPad_D3.0mm_Drill1.5mm
TestPoint:TestPoint_THTPad_D3.0mm_Drill1.5mm
Connectors:TestPoint_2Pads_Pitch5.08mm_Drill1.5mm
Package_TO_SOT_SMD:SOT-23-5_HandSoldering
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer
Mfg Part No
YAGEO
RC0603FR-133KL
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5013
KEYSTONE
5288
KEYSTONE
5013
ANALOG DEVICES
LTC6101VHVCHS5#TRMPBF
UM90029
DNP
DNP = DO NOT POPULATE
Nexperia B.V. 2024. All rights reserved
©
59 / 64
