Reference
Qty
Value
J11
1
Signals2
J12
1
HALL
JP1
1
VDD
JP2
1
PWR
L1
1
22u
R1
1
3.9k
R2
1
75k-1%
R3
1
10k-1%
R4
1
100k
R5
1
8.66k-1%
R6, R33, R34,
4
0
R45
R7
1
1M-0.5%
R8
1
71.5k-1%
R9
1
1.2k
R10, R20, R21,
8
0
R24, R29, R30,
R37, R44
R11, R16, R17,
7
1k
R18, R19, R22,
R23
R12, R14, R15,
6
10k
R46, R47, R48
R13
1
750
R25, R27, R35,
4
110k-1%
R41
R26, R28, R36,
4
4.99k-1%
R42
UM90029
Submit document feedback
User manual
Footprint
Connector_PinHeader_2.54mm:PinHeader_2x07_P2.54mm_Horizontal WURTH
Connector_Phoenix_MC:PhoenixContact_MCV_1,5_5-
G-3.5_1x05_P3.50mm_Vertical
Connector_PinHeader_2.54mm:PinHeader_1x03_P2.54mm_Vertical
Connector_PinHeader_2.54mm:PinHeader_2x01_P2.54mm_Vertical
Inductor_SMD:L_Bourns_SRP1038C_10.0x10.0mm
Resistor_SMD:R_1206_3216Metric_Pad1.30x1.75mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_1206_3216Metric_Pad1.30x1.75mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer
Mfg Part No
61301421021
ELEKTRONIK
CAMDENBOSS
CTBP93VD/5
MULTICOMP PRO
2211S-03G
MULTICOMP PRO
2211S-02G
BOURNS
SRP1038A-220M
BOURNS
CR1206-FX-3901ELF
YAGEO
AC0603FR-0775KL
KAMAYA
RMC1/16103JTP
YAGEO
RT0603FRE07100KL
YAGEO
RC0603FR-078K66L
YAGEO
RC0603FR-070RL
YAGEO
RC0603DR-071ML
YAGEO
RE0603FRE0771K5L
YAGEO
RC1206JR-071K2L
YAGEO
RC0603FR-070RL
KAMAYA
RMC1/16-102JTP
KAMAYA
RMC1/16103JTP
BOURNS
CR0603-JW-751ELF
YAGEO
AC0603FR-07110KL
PANASONIC
ERJ-3EKF4991V
UM90029
DNP
Nexperia B.V. 2024. All rights reserved
©
