8.5. Bill of Materials
Table 17. Motor control board (NEVB-MCTRL-100-01) Bill of Materials
Reference
Qty
Value
C1
1
10u-100V
C2
1
2.2u-100V
C3
1
2.2u-16V
C4
1
10n
C5
1
0.1u-100V
C6
1
1u-25V
C7
1
1u-10V
C8, C15, C17,
5
0.1u-25V
C19, C32
C9
1
10p
C10
1
47u-16V
C11
1
22u-16V
C12
1
1u-16V
C13, C14, C16,
6
1u-25V
C18, C20, C21
C22, C23, C24,
6
0.1u-16V
C25, C26, C27
C28
1
47n
C29, C30, C31
3
1n
D1
1
PTVS60VP1UTP
D2
1
Green
D3
1
PMEG100T20ELR
D4
1
PMEG3010CEJ
D5
1
EN
D6
1
RMT
UM90029
Submit document feedback
User manual
Footprint
Capacitor_SMD:CP_Elec_6.3x9.9
Capacitor_SMD:C_1210_3225Metric_Pad1.33x2.70mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_1210_3225Metric_Pad1.33x2.70mm_HandSolder
Capacitor_SMD:C_1210_3225Metric_Pad1.33x2.70mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Capacitor_SMD:C_0603_1608Metric_Pad1.08x0.95mm_HandSolder
Diode_SMD:D_SOD-128
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
Diode_SMD:D_SOD-123F
Diode_SMD:D_SOD-323F
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer
Mfg Part No
WURTH
865060845002
ELEKTRONIK
SAMSUNG
CL32B225KCJSNNE
YAGEO
CC0603KRX7R7BB225
MURATA
GRM188R72A103KA01J
SAMSUNG
CL10B104KC8NNNC
SAMSUNG
CL10B105KA8NNNC
SAMSUNG
CL10B105KA8NNNC
SAMSUNG
CL10B104KC8NNNC
YAGEO
CC0603JRNPO0BN100
MURATA
GRM32EC81C476KE15L
SAMSUNG
CL32A226MOJNNNE
SAMSUNG
CL10B105KA8NNNC
SAMSUNG
CL10B105KA8NNNC
SAMSUNG
CL10B104KC8NNNC
YAGEO
CC0603KRX7R9BB473
MULTICOMP PRO
MC0603B102K500CT
NEXPERIA
PTVS60VP1UTP,115
MULTICOMP PRO
MP008280
NEXPERIA
PMEG100T20ELR-QX
NEXPERIA
PMEG3010CEJ,115
DIALIGHT
599-0230-007F
MULTICOMP PRO
MP008280
UM90029
DNP
DNP
DNP
