Nexperia
Reference Qty Value
D7 1 NHC
D8 1 U1
D9 1 U2
D10 1 U3
D11 1 REV
D12 1 STP
D13 1 OC
D14 1 BZX84-C56
D15 1 OV
G1, G3 2 2.54mm Jumper
G2, G6, G8, G12 4 M3x8mm Screw
G4, G5, G9, G10 4 M3x30mm F/F
Standoff
G7 1 For J2
G11 1 For J12
J1 1 VIN
J2 1 VDD
J3, J9 2 Conn_02x19
J4 1 Power
J5 1 AO
J6 1 ICSP
J7 1 IOH
J8 1 IOL
J10 1 Signals1
UM90029
Submit document feedback
User manual
Footprint
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
Package_TO_SOT_SMD_Custom:SOT-23-Nexperia-Diode
LED_SMD:LED_1206_3216Metric_Pad1.42x1.75mm_HandSolder
Connector_PinHeader_2.54mm:PinHeader_2x04_P2.54mm_Horizontal WURTH
Connector_Phoenix_MC:PhoenixContact_MCV_1,5_2-
G-3.5_1x02_P3.50mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_2x19_P2.54mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_1x08_P2.54mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_1x06_P2.54mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_2x03_P2.54mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_1x10_P2.54mm_Vertical
Connector_PinSocket_2.54mm:PinSocket_1x08_P2.54mm_Vertical
Connector_PinHeader_2.54mm:PinHeader_2x07_P2.54mm_Horizontal WURTH
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer Mfg Part No
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
MULTICOMP PRO MP008281
NEXPERIA BZX84-C56,215
MULTICOMP PRO MP008281
HARWIN M7685-05
RS PRO 264-6436
RS PRO 806-6610
TE CONNECTIVITY 2350398-2
IMO PRECISION 20.1551M/5-E
CONTROLS
61300821021
ELEKTRONIK
AMPHENOL ANYTEK OQ02125000J0G
SAMTEC SSQ-119-03-T-D
SAMTEC SSQ-108-03-T-S
SAMTEC SSQ-106-03-T-S
SAMTEC SSQ-103-03-T-D
SAMTEC SSQ-110-03-T-S
SAMTEC SSQ-108-03-T-S
61301421021
ELEKTRONIK
